52
STR-DE598/DE698/DV10
Ver. 1.1
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CNS502 1-766-719-41 CONNECTOR, BOARD TO BOARD 10P
CNS504 1-568-826-11 CONNECTOR, FFC 7P
CNS505 1-568-838-11 CONNECTOR, FFC 21P
CNS508 1-568-830-11 CONNECTOR, FFC 11P (EXCEPT AEP,UK)
CNS508 1-784-776-11 CONNECTOR, FFC 15P (AEP,UK)
CNS509 1-784-774-11 CONNECTOR, FFC 13P
< DIODE >
D1001 8-719-053-18 DIODE 1SR154-400TE-25
D1003 8-719-049-09 DIODE 1SS367-T3SONY
D1004 8-719-049-09 DIODE 1SS367-T3SONY
D1103 8-719-988-61 DIODE 1SS355TE-17
D1105 8-719-988-61 DIODE 1SS355TE-17
D1106 8-719-988-61 DIODE 1SS355TE-17
D1107 8-719-988-61 DIODE 1SS355TE-17
D1108 8-719-988-61 DIODE 1SS355TE-17
D1110 8-719-988-61 DIODE 1SS355TE-17
D1111 8-719-988-61 DIODE 1SS355TE-17
D1301 8-719-988-61 DIODE 1SS355TE-17
D1302 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB1101 1-400-862-11 BEAD, FERRITE
FB1302 1-400-862-11 BEAD, FERRITE
FB1305 1-400-862-11 BEAD, FERRITE
FB1306 1-400-862-11 BEAD, FERRITE
FB1308 1-400-862-11 BEAD, FERRITE
FB1309 1-400-862-11 BEAD, FERRITE (DE698/DV10)
FB1405 1-400-862-11 BEAD, FERRITE
FB1452 1-400-862-11 BEAD, FERRITE
FB1453 1-400-862-11 BEAD, FERRITE
FB1501 1-400-862-11 BEAD, FERRITE
FB1502 1-400-862-11 BEAD, FERRITE
FB1503 1-400-862-11 BEAD, FERRITE
FB1504 1-400-862-11 BEAD, FERRITE (DE698/DV10)
< IC >
IC1001 8-759-231-53 IC TA7805S
IC1031 6-705-464-01 IC BA50BC0T
IC1071 6-702-771-01 IC TA78033LS (AEP,UK)
IC1101 6-804-835-01 IC MB90488BPF-G-110E1 (DE698/DV10)
IC1101 6-805-148-01 IC MB90488BPF-G-137E1 (DE598)
IC1103 8-759-242-70 IC TC7WU04F (DE698/DV10)
IC1111 6-702-913-01 IC S-80929CNMC-G8ZT2G
IC1131 6-704-004-01 IC BR24L16F-WE2
IC1301 8-759-825-15 IC LC89056W-E
IC1302 8-759-595-15 IC TC74ACT153F(EL) (DE698/DV10)
IC1303 8-759-242-70 IC TC7WU04F
IC1351 6-600-014-01 IC TORX141L (DIGITAL
VIDEO 2 IN (OPTICAL))
IC1352 6-600-014-01 IC TORX141L (DIGITAL
MD/TAPE IN (OPTICAL)) (DE698/DV10)
IC1353 6-600-012-11 IC TOTX141L(RED) (DIGITAL
MD/TAPE OUT (OPTICAL)) (DE698/DV10)
IC1354 6-600-014-01 IC TORX141L (DIGITAL
SA-CD/CD IN (OPTICAL))
IC1401 8-759-560-56 IC PCM1800E/2K
IC1403 8-759-710-97 IC NJM4565M-D
IC1404 8-759-710-97 IC NJM4565M-D
IC1405 8-759-710-97 IC NJM4565M-D
IC1406 8-759-710-97 IC NJM4565M-D
IC1452 6-703-787-01 IC PCM1609KPTR
IC1501 6-705-900-01 IC CXD9718BQ
IC1502 6-704-037-01 IC IC61LV6416-15TG
IC1503 8-759-546-74 IC TC7WH157FU(TE12R)
IC1506 8-759-546-74 IC TC7WH157FU(TE12R) (DE698/DV10)
IC1507 6-707-666-01 IC NJU26902VM1-TE2 (DE698/DV10)
IC1901 6-701-887-02 IC SI-3004KWF
IC1902 6-703-550-01 IC TA7809LS
IC1904 6-705-463-01 IC BA33BC0T
< JACK >
J1301 1-794-972-11 JACK, PIN 1P (DIGITAL DVD IN (COAXIAL))
(DE598)
J1301 1-818-314-11 JACK, PIN 2P (DIGITAL DVD IN (COAXIAL),
SA-CD/CD IN (COAXIAL)) (DE698/DV10)
< JUMPER RESISTOR >
JR1020 1-216-864-11 SHORT CHIP 0
JR1201 1-211-950-11 SHORT CHIP 0
JR1202 1-216-864-11 SHORT CHIP 0 (EXCEPT AEP,UK)
JR1203 1-216-296-11 SHORT CHIP 0
JR1204 1-211-950-11 SHORT CHIP 0
JR1206 1-211-950-11 SHORT CHIP 0
JR1211 1-216-296-11 SHORT CHIP 0
JR1212 1-216-296-11 SHORT CHIP 0
JR1214 1-216-296-11 SHORT CHIP 0
JR1215 1-216-296-11 SHORT CHIP 0
JR1302 1-216-864-11 SHORT CHIP 0 (DE598)
JR1303 1-216-864-11 SHORT CHIP 0 (DE598)
JR1501 1-216-864-11 SHORT CHIP 0
JR1511 1-400-862-11 BEAD, FERRITE
< TRANSISTOR >
Q1103 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q1104 8-729-230-49 TRANSISTOR 2SC2712-YG
Q1105 8-729-230-49 TRANSISTOR 2SC2712-YG
< RESISTOR >
R1018 1-216-864-11 SHORT CHIP 0 (DE598)
R1019 1-216-864-11 SHORT CHIP 0 (DE598)
R1035 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1039 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1041 1-216-809-11 METAL CHIP 100 5% 1/10W
R1042 1-216-809-11 METAL CHIP 100 5% 1/10W
R1044 1-216-809-11 METAL CHIP 100 5% 1/10W
R1049 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1052 1-216-833-11 METAL CHIP 10K 5% 1/10W
(DE598)
R1053 1-216-833-11 METAL CHIP 10K 5% 1/10W
(DE598)
R1055 1-216-809-11 METAL CHIP 100 5% 1/10W
(DE698/DV10)
R1056 1-216-854-11 METAL CHIP 560K 5% 1/10W
(DE698/DV10)
R1057 1-216-837-11 METAL CHIP 22K 5% 1/10W
(DE698/DV10)
