58
STR-DE598/DE698/DV10
Ver. 1.1
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CC01 1-162-282-31 CERAMIC 100PF 10% 50V
(DE698:AEP,UK,AUS,AR)
CC02 1-162-282-31 CERAMIC 100PF 10% 50V
(EXCEPT US,CND,E2)
CC04 1-162-282-31 CERAMIC 100PF 10% 50V
(EXCEPT US,CND,E2)
CC05 1-162-282-31 CERAMIC 100PF 10% 50V
(EXCEPT US,CND,E2)
CC06 1-162-282-31 CERAMIC 100PF 10% 50V
(EXCEPT US,CND,E2)
CC07 1-162-282-31 CERAMIC 100PF 10% 50V
(EXCEPT US,CND,E2)
CC08 1-162-282-31 CERAMIC 100PF 10% 50V
(EXCEPT US,CND,E2)
CC09 1-162-282-31 CERAMIC 100PF 10% 50V
(EXCEPT US,CND,E2)
CC11 1-127-876-11 CERAMIC 0.01uF 10% 50V
(EXCEPT US,CND,E2)
CC13 1-127-876-11 CERAMIC 0.01uF 10% 50V
(EXCEPT US,CND,E2)
CC15 1-127-876-11 CERAMIC 0.01uF 10% 50V
(EXCEPT US,CND,E2)
CC17 1-127-876-11 CERAMIC 0.01uF 10% 50V
(EXCEPT US,CND,E2)
CC31 1-162-286-31 CERAMIC 220PF 10% 50V
(EXCEPT US,CND,E2)
CC32 1-162-286-31 CERAMIC 220PF 10% 50V
(EXCEPT US,CND,E2)
CC33 1-162-286-31 CERAMIC 220PF 10% 50V
(EXCEPT US,CND,E2)
CC34 1-162-286-31 CERAMIC 220PF 10% 50V
(EXCEPT US,CND,E2)
CC35 1-162-286-31 CERAMIC 220PF 10% 50V
(EXCEPT US,CND,E2)
CC36 1-162-286-31 CERAMIC 220PF 10% 50V
(EXCEPT US,CND,E2)
CC51 1-162-282-31 CERAMIC 100PF 10% 50V
(DE698:AEP,UK,AUS,AR)
CC52 1-162-282-31 CERAMIC 100PF 10% 50V
(EXCEPT US,CND,E2)
CC54 1-162-282-31 CERAMIC 100PF 10% 50V
(EXCEPT US,CND,E2)
CC55 1-162-282-31 CERAMIC 100PF 10% 50V
(EXCEPT US,CND,E2)
CC56 1-162-282-31 CERAMIC 100PF 10% 50V
(EXCEPT US,CND,E2)
CC57 1-162-282-31 CERAMIC 100PF 10% 50V
(EXCEPT US,CND,E2)
CC58 1-162-282-31 CERAMIC 100PF 10% 50V
(EXCEPT US,CND,E2)
CC59 1-162-282-31 CERAMIC 100PF 10% 50V
(EXCEPT US,CND,E2)
< CONNECTOR >
CNP500 1-766-715-21 CONNECTOR, BOARD TO BOARD 10P
CNP501 1-573-847-11 CONNECTOR, BOARD TO BOARD 15P
CNP503 1-779-978-11 PIN, CONNECTOR 3P
CNP802 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
CNP806 1-784-921-11 PIN, CONNECTOR 4P
* CNP908 1-564-242-00 PIN, CONNECTOR (3.96mm PITCH) 5P
CNP911 1-784-926-11 PIN, CONNECTOR 11P
CNP912 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
< DIODE >
D505 8-719-991-33 DIODE 1SS133T-77
D540 8-719-991-33 DIODE 1SS133T-77
D560 8-719-991-33 DIODE 1SS133T-77
D580 8-719-991-33 DIODE 1SS133T-77
D585 8-719-991-33 DIODE 1SS133T-77
D605 8-719-991-33 DIODE 1SS133T-77
D610 8-719-991-33 DIODE 1SS133T-77
D640 8-719-991-33 DIODE 1SS133T-77
D665 8-719-991-33 DIODE 1SS133T-77
D680 8-719-991-33 DIODE 1SS133T-77
D690 8-719-934-21 DIODE HZS30-1L
D691 8-719-991-33 DIODE 1SS133T-77
D705 8-719-991-33 DIODE 1SS133T-77
D710 8-719-991-33 DIODE 1SS133T-77
D721 8-719-991-33 DIODE 1SS133T-77
D722 8-719-991-33 DIODE 1SS133T-77
D732 8-719-991-33 DIODE 1SS133T-77
D740 8-719-991-33 DIODE 1SS133T-77
D750 8-719-991-33 DIODE 1SS133T-77
D765 8-719-991-33 DIODE 1SS133T-77
D791 8-719-991-33 DIODE 1SS133T-77
D801 8-719-933-95 DIODE HZS20-1L
D802 8-719-072-05 DIODE RBV-602LF-A
D804 8-719-068-28 DIODE HZ6.8BP-TK
D805 6-500-522-11 DIODE 10EDB40-TA2B5
D806 6-500-522-11 DIODE 10EDB40-TA2B5
D807 6-500-522-11 DIODE 10EDB40-TA2B5
D808 6-500-522-11 DIODE 10EDB40-TA2B5
D818 8-719-991-33 DIODE 1SS133T-77
D896 8-719-043-76 DIODE AK04V0
< IC >
IC401 6-707-362-01 IC BD3451KS
IC402 8-759-167-88 IC NJM4565D
IC501 6-700-943-01 IC uPC2581V-S
IC601 6-700-943-01 IC uPC2581V-S
IC691 8-759-167-88 IC NJM4565D
IC701 6-700-943-01 IC uPC2581V-S
IC801 8-759-071-48 IC TA7807S
IC802 8-759-071-47 IC TA79007S
< JACK >
J309 1-770-377-21 JACK, PIN 1P (SUB WOOFER AUDIO OUT)
J400 1-774-411-11 JACK, PIN 6P (MD/TAPE OUT,SA-CD/CD IN,
AUX IN) (DE698/DV10)
J401 1-793-775-12 JACK, PIN 6P (MULTI CH IN
FRONT,SURROUND,CENTER,SUB WOOFER)
J402 1-770-614-11 JACK, PIN 4P (MD/TAPE OUT,SA-CD/CD IN)
(DE598)
J403 1-770-614-11 JACK, PIN 4P (MD/TAPE IN,DVD AUDIO IN)
J404 1-774-411-11 JACK, PIN 6P (VIDEO 2 AUDIO IN,
VIDEO 1 AUDIO OUT/IN)
< COIL >
L601 1-420-872-52 COIL, AIR-CORE
L651 1-420-872-52 COIL, AIR-CORE
L701 1-420-872-52 COIL, AIR-CORE
MAIN
