61
STR-DE598/DE698/DV10
Ver. 1.1
R740 1-247-863-00 CARBON 22K 5% 1/4W
R741 1-249-431-11 CARBON 15K 5% 1/4W
R743 1-249-431-11 CARBON 15K 5% 1/4W
R744 1-249-431-11 CARBON 15K 5% 1/4W
R745 1-247-847-00 CARBON 4.7K 5% 1/4W
(DE598)
R745 1-247-871-00 CARBON 47K 5% 1/4W
(DE698/DV10)
R746 1-247-863-00 CARBON 22K 5% 1/4W
(DE698/DV10)
R746 1-247-871-00 CARBON 47K 5% 1/4W
(DE598)
R747 1-249-431-11 CARBON 15K 5% 1/4W
R748 1-249-431-11 CARBON 15K 5% 1/4W
R750 1-247-863-00 CARBON 22K 5% 1/4W
R751 1-247-831-00 CARBON 1K 5% 1/4W
R752 1-249-439-11 CARBON 68K 5% 1/4W
R753 1-249-421-11 CARBON 2.2K 5% 1/4W
R754 1-249-439-11 CARBON 68K 5% 1/4W
R755 1-247-847-00 CARBON 4.7K 5% 1/4W
(DE598)
R755 1-247-871-00 CARBON 47K 5% 1/4W
(DE698/DV10)
R756 1-247-863-00 CARBON 22K 5% 1/4W
(DE698/DV10)
R756 1-247-871-00 CARBON 47K 5% 1/4W
(DE598)
R757 1-249-431-11 CARBON 15K 5% 1/4W
R758 1-249-431-11 CARBON 15K 5% 1/4W
R760 1-249-421-11 CARBON 2.2K 5% 1/4W
R761 1-249-440-11 CARBON 82K 5% 1/4W
R763 1-249-414-11 CARBON 560 5% 1/4W
R764 1-249-399-11 CARBON 33 5% 1/4W F
R765 1-249-399-11 CARBON 33 5% 1/4W F
R766 1-234-182-11 ENCAPSULATED COMPONENT 0.22X2 5W
R767 1-249-393-11 CARBON 10 5% 1/4W F
R768 1-249-389-11 CARBON 4.7 5% 1/4W F
R769 1-247-847-00 CARBON 4.7K 5% 1/4W
R771 1-240-855-81 CARBON 6.2K 5% 1/4W F
R772 1-249-419-11 CARBON 1.5K 5% 1/4W
R773 1-247-871-00 CARBON 47K 5% 1/4W
R775 1-249-439-11 CARBON 68K 5% 1/4W
R778 1-249-431-11 CARBON 15K 5% 1/4W
R780 1-249-429-11 CARBON 10K 5% 1/4W
R791 1-249-421-11 CARBON 2.2K 5% 1/4W
0 R792 1-215-868-00 METAL OXIDE 680 5% 1W F
R793 1-249-404-00 CARBON 82 5% 1/4W F
0 R794 1-215-868-00 METAL OXIDE 680 5% 1W F
R802 1-249-409-11 CARBON 220 5% 1/4W F
R803 1-249-389-11 CARBON 4.7 5% 1/4W F
R804 1-249-429-11 CARBON 10K 5% 1/4W
R806 1-247-863-00 CARBON 22K 5% 1/4W
R824 1-249-421-11 CARBON 2.2K 5% 1/4W
R830 1-249-404-00 CARBON 82 5% 1/4W F
(CND)
R831 1-249-404-00 CARBON 82 5% 1/4W F
0 R910 1-240-877-11 FUSIBLE 0.15 5% 1/2W F
RR11 1-249-393-11 CARBON 10 5% 1/4W F
(EXCEPT US,CND,E2)
Ref. No. Part No. Description Remark
RR12 1-249-393-11 CARBON 10 5% 1/4W F
(EXCEPT US,CND,E2)
RR13 1-249-393-11 CARBON 10 5% 1/4W F
(EXCEPT US,CND,E2)
RR14 1-249-393-11 CARBON 10 5% 1/4W F
(EXCEPT US,CND,E2)
< RELAY >
RY560 1-755-267-11 RELAY
RY601 1-755-170-11 RELAY (12V)
RY701 1-755-170-11 RELAY (12V)
RY791 1-755-170-11 RELAY (12V)
RY801 1-755-013-11 RELAY (EXCEPT CND)
RY802 1-755-494-11 RELAY (CND)
RY803 1-755-494-11 RELAY (CND)
< TERMINAL BOARD >
TM601 1-780-216-11 TERMINAL BOARD (8P) (SPEAKERS
FRONT A,SURROUND)
*************************************************************
OPT3 BOARD (DE698/DV10)
***********
< CAPACITOR >
C290 1-127-888-11 CERAMIC 0.1uF 10% 50V
< CONNECTOR >
CN202 1-779-978-21 PIN, CONNECTOR 3P
< IC >
IC200 6-600-057-01 IC TORX141PL (VIDEO 3 INPUT
DIGITAL(OPT))
< COIL >
L290 1-410-517-11 INDUCTOR 47uH
< RESISTOR >
R290 1-247-807-31 CARBON 100 5% 1/4W
*************************************************************
POWER BOARD
*************
< CONNECTOR >
* CNP102 1-564-518-11 PLUG, CONNECTOR 3P
< RESISTOR >
R129 1-249-421-11 CARBON 2.2K 5% 1/4W
R130 1-247-847-00 CARBON 4.7K 5% 1/4W
< SWITCH >
S128 1-771-410-21 SWITCH, TACTILE (SPEAKERS (OFF/A/B/A+B))
S129 1-771-410-21 SWITCH, TACTILE (DISPLAY)
S130 1-771-410-21 SWITCH, TACTILE (DIMMER)
S131 1-771-410-21 SWITCH, TACTILE (?/1)
*************************************************************
Ref. No. Part No. Description Remark
