63
STR-DE598/DE698/DV10
Ver. 1.1
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
TM502 1-780-217-11 TERMINAL BOARD (2P) (SPEAKERS
SURROUND BACK R) (DE698/DV10)
*************************************************************
SPEAKER B (P) BOARD (DE598)
*******************
< CAPACITOR >
CC30 1-127-876-11 CERAMIC 0.01uF 10% 50V
(DE598:EXCEPT US,CND,E2)
CC31 1-127-876-11 CERAMIC 0.01uF 10% 50V
(DE598:EXCEPT US,CND,E2)
< CONNECTOR >
CNP610 1-785-102-11 PIN, CONNECTOR (3.96mm PITCH) 4P (DE598)
CNP611 1-779-978-11 PIN, CONNECTOR 3P (DE598)
< DIODE >
D810 8-719-991-33 DIODE 1SS133T-77 (DE598)
< TRANSISTOR >
Q810 8-729-119-78 TRANSISTOR 2SC2785-HFE (DE598)
< RESISTOR >
R810 1-249-404-00 CARBON 82 5% 1/4W F
(DE598)
R811 1-249-421-11 CARBON 2.2K 5% 1/4W
(DE598)
RR30 1-249-393-11 CARBON 10 5% 1/4W F
(DE598:EXCEPT US,CND,E2)
RR31 1-249-393-11 CARBON 10 5% 1/4W F
(DE598:EXCEPT US,CND,E2)
< RELAY >
RY610 1-755-170-11 RELAY (12V) (DE598)
< TERMINAL BOARD >
* TM610 1-537-240-21 TERMINAL BOARD (CHECKER PIN) (4P)
(SPEAKERS FRONT B) (DE598)
*************************************************************
SPEAKER B (S) BOARD (DE698/DV10)
*******************
< CAPACITOR >
CC20 1-127-876-11 CERAMIC 0.01uF 10% 50V
(DE698:AEP,UK,AUS,AR)
CC21 1-127-876-11 CERAMIC 0.01uF 10% 50V
(DE698:AEP,UK,AUS,AR)
< CONNECTOR >
CNP600 1-785-102-11 PIN, CONNECTOR (3.96mm PITCH) 4P
(DE698/DV10)
CNP601 1-779-978-11 PIN, CONNECTOR 3P (DE698/DV10)
< DIODE >
D800 8-719-991-33 DIODE 1SS133T-77 (DE698/DV10)
< TRANSISTOR >
Q800 8-729-119-78 TRANSISTOR 2SC2785-HFE (DE698/DV10)
< RESISTOR >
R800 1-249-404-00 CARBON 82 5% 1/4W F
(DE698/DV10)
R812 1-249-421-11 CARBON 2.2K 5% 1/4W
(DE698/DV10)
RR20 1-249-393-11 CARBON 10 5% 1/4W F
(DE698:AEP,UK,AUS,AR)
RR21 1-249-393-11 CARBON 10 5% 1/4W F
(DE698:AEP,UK,AUS,AR)
< RELAY >
RY600 1-755-170-11 RELAY (12V) (DE698/DV10)
< TERMINAL BOARD >
TM600 1-780-215-11 TERMINAL BOARD (4P) (SPEAKERS FRONT B)
(DE698/DV10)
*************************************************************
A-1084-334-A STANDBY BOARD, COMPLETE (DE598:US,CND)
A-1084-405-A STANDBY BOARD, COMPLETE
(DE598:AEP,UK,AUS,AR,KR/DE698:AR)
A-1084-703-A STANDBY BOARD, COMPLETE (DE598:TW)
A-1084-969-A STANDBY BOARD, COMPLETE
(DE698:US,CND/DV10)
A-1084-975-A STANDBY BOARD, COMPLETE (DE598:E2)
A-1085-098-A STANDBY BOARD, COMPLETE (DE698:AEP,UK)
A-1085-210-A STANDBY BOARD, COMPLETE (DE698:AUS)
A-1085-251-A STANDBY BOARD, COMPLETE (DE698:E2)
*************************
1-533-217-41 HOLDER, FUSE
< CAPACITOR >
C913 1-127-888-11 CERAMIC 0.1uF 10% 50V
C914 1-127-888-11 CERAMIC 0.1uF 10% 50V
C915 1-126-943-11 ELECT 2200uF 20% 25V
C916 1-126-942-61 ELECT 1000uF 20% 25V
C920 1-127-888-11 CERAMIC 0.1uF 10% 50V
C921 1-127-888-11 CERAMIC 0.1uF 10% 50V
C922 1-127-888-11 CERAMIC 0.1uF 10% 50V
C924 1-126-960-11 ELECT 1uF 20% 50V
C950 1-126-936-11 ELECT 3300uF 20% 16V
< CONNECTOR >
CNP801 1-784-922-11 PIN, CONNECTOR 5P
CNP804 1-564-506-11 PLUG, CONNECTOR 3P
CNP901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CNP902 1-794-577-21 PIN, CONNECTOR (POWER) 2P
CNP903 1-784-922-11 PIN, CONNECTOR 5P
CNP906 1-568-106-11 PIN, CONNECTOR (3.96mm PITCH) 4P (E2)
< DIODE >
D901 8-719-991-33 DIODE 1SS133T-77
D910 6-500-522-11 DIODE 10EDB40-TA2B5
D911 6-500-522-11 DIODE 10EDB40-TA2B5
D912 6-500-522-11 DIODE 10EDB40-TA2B5
SPEAKER B (P) SPEAKER B (S) STANDBYSPEAKER C/SB
