Sony STR-DH730 - Waveform Analysis; Waveform Examples by Board and IC

STR-DH730/DH830
45
• Waveforms
– DIGITAL Board –
– D-VIDEO Board –
– STANDBY-AVIDEO PC Board –
– DISPLAY Board –
3.28 Vp-p
4 MHz
1 IC2105 os (X2101(X_OUT))
100 mV/DIV, 100 nsec/DIV
3.34 Vp-p
47.6 kH
2 IC2006 qk (LRCK)
100 mV/DIV, 10 usec/DIV
3 IC2006 ql (BCK)
3.34 Vp-p
3.00 MHz
100 mV/DIV, 100 nsec/DIV
5
IC3201 qs (XTAL)
20 mV/DIV, 20 ns/DIV
19.6608MHz
86 m Vp-p
4
IC3000 wf (X3000(XOUT))
2.0 mV/DIV, 100 ns/DIV
4.00MHz
3.2 Vp-p
20 mV/DIV, 20 s/DIV
H
0.5 Vp-p
7
IC220 ws (CH2 OUT)
(Color bar)
6
IC220 w; (CH3 OUT)
(Color bar)
20 mV/DIV, 10 s/DIV
H
0.5 Vp-p
50 mV/DIV, 10 s/DIV
H
0.8 Vp-p
8
IC220 wf (CH1 OUT)
(Color bar)
9 IC100 5 (OSC)
50 mV/DIV, 1
sec/DIV
15 s
4.72 Vp-p
