STR-DH730/DH830
55
Pin No. Pin Name I/O Description
55 NO_USE - Not used
56 NO_USE - Not used
57 NO_USE - Not used
58 NO_USE - Not used
59 NO_USE - Not used
60 NO_USE - Not used
61 NO_USE - Not used
62 H2_POWER_CONT O Hudson 2: Power Control
63 FLI_BUSY I Hudson 2: Busy Notifi cation
64 HSYNC_SEL O Hudson 2: Horizontal sync selection signal output to the HSYNC select
65 FLI_SDA I/O Hudson 2: Communication Line I2C SDA
66 NO_USE - Not used
67 FLI_SCL I/O Hudson 2: Communication Line I2C SCL
68 FLI_RESET O Hudson 2: RESET Hudson 2
69 NO_USE - Not used
70 TEST_1 O Test Pad 1 ( for designer evaluation only)
71 TEST_2 O Test Pad 2 ( for designer evaluation only)
72 TEST_3 O Test Pad 3 ( for designer evaluation only)
73 TEST_4 O Test Pad 4 ( for designer evaluation only)
74 TEST_5 O Test Pad 5 ( for designer evaluation only)
75 NO_USE - Not used
76 USB_MCHNG I USB: MCHNG (change of music fi le being playback) from USB Device BU94604BKV
77 USB_BUSY I BUSY signal communication between USB board
78 USB_RESET O USB: RESET for USB Device BU94604BKV
79 USB_IP_RESET O USB: RESET for iPod certifi cation IC
80 NO_USE - Not used
81 USB_SDA I/O USB: Communication Line I2C SDA
82 NO_USE - Not used
83 USB_SCL I/O USB: Communication Line I2C SCL
84 USB_OVC I USB: Overcurrent Detection
85 USB_IP_SDA I/O USB: Data Communication line - I2C SDA for iPod certifi cation IC
86 NO_USE - Not used
87 USB_IP_SCL I/O USB: Data Communication line - I2C SCL for iPod certifi cation IC
88 USB_IRPTO I
USB: IRPTO (notifi cation that two USB confi guration descriptor or more is connected) from
USB Device BU94604BKV
89 USB_REG_CTRL I USB: IOCP (Regulator Control for USB overcurrent detection) Control Line
90 NO_USE - Not used
91 NO_USE - Not used
92 NO_USE - Not used
93 I2C_TEST_SDA O Monitor HA-Link I2C ( for designer evaluation only)
94 NO_USE - Not used
95 I2C_TEST_SCL O Monitor HA-Link I2C ( for designer evaluation only)
96 MU_RST I USB Update: USB Update Main Micom Reset
97 MU_MD0 I USB Update: USB Update MD0 select
98 5V_RX0_IN I/O HDMI: for 5-in solution
99 NO_USE - Not used
100 VCC - Power supply terminal
