D-VIDEO BOARD (2/5) IC3201 FLI30502AC (VIDEO CONTROLLER)
Pin No. Pin Name I/O Description
1 VDDA33_LBADC
-
Power supply terminal (+3.3V)
2 LBADC_IN1 I Standby signal input from the system controller
3 to 6
LBADC_IN2 to
LBADC_IN5
-
Not Used
7 VDDA33_LBADC
-
Power supply terminal (+3.3V)
8 RESETn I Reset signal input from the system controller
9 VBUFC_RPLL
-
Not Used
10 VDD_RPLL_18
-
Power supply terminal (+1.8V)
11 GND_RPLL
-
Ground terminal
12 XTAL O System clock output terminal (19.6 MHz)
13 TCLK I System clock input terminal (19.6 MHz)
14 AVDD_RPLL_33
-
Power supply terminal (+3.3V)
15 VSYNC1_VGA
-
Not Used
16 HSYNC1_VGA
-
Not Used
17 STI_TM2
-
Not Used
18
GPIO15/STI_TM1/
EXT_CSn
-
Not Used
19 SCART16
-
Not Used
20 CVDD_18
-
Power supply terminal (+3.3V)
21 CRVSS
-
Ground terminal
22
HOST_SCLK/
UART_DI/JTAG_CLK
O Serial data input from the connector (for RS-232C) and DSP
23
HOST_SDATA/
UART_DO/
JTAG_MODE
I Serial data output to the connector (for RS-232C) and DSP
24 DDC_SCLK
-
Not Used
25 DDC_SDATA
-
Not Used
26 CVDD_18
-
Power supply terminal (+1.8V)
27 CRVSS
-
Ground terminal
28 MSTR_SCLK O Clock signal output to the EEPROM
29 MSTR_SDATA I/O Two-way serial data with the EEPROM
30 RVDD_33
-
Power supply terminal (+3.3V)
31 CRVSS
-
Ground terminal
32 to 35 GPIO0 to GPIO3
-
Not Used
36 GPIO6/IRin
-
Not Used
37 CVDD_18
-
Power supply terminal (+1.8V)
38 CRVSS
-
Ground terminal
39 GPIO7/IRQin
-
Not Used
40 GPIO8/IRQout
-
Not Used
41
GPIO9/SIPC_SCLK/
A19
I I2C data input from the system controller
42
GPIO10/
SIPC_SDA
TA/A20
I I2C clock signal input from the system controller
43 CVDD_18
-
Power supply terminal (+1.8V)
44 CRVSS
-
Ground terminal
45, 46
GPIO11/PWM0,
GPIO12/PWM1
-
Not Used
47 RVDD_33
-
Power supply terminal (+3.3V)
48 CRVSS
-
Ground terminal
49
GPIO13/PWM2/
JTAG_RESET
-
Not Used
50
GPIO14/PWM3/
SCART16_1
-
Not Used
51 CVDD_18
-
Power supply terminal (+1.8V)
52 CRVSS
-
Ground terminal
53 GPIO4/VIDIN_HS
-
Not Used
54 GPIO5/VIDIN_VS
-
Not Used
To Next Page
