MULTI CHANNEL AV RECEIVER

STR-DN1050/STR-DN850

Connecting an MHL-compatible mobile device

Connect an MHL-compatible mobile device as illustrated below.

This receiver supports MHL 2 technology.

Front (for STR-DN1050 only)

Rear

Mobile device

MHL cable (not supplied)

Use an MHL 2-compliant cable.

Sony recommends that you use an MHL cable made by Sony.

MHL Direct Attach Device

Related Topic

Using MHL (Mobile High-Definition Link) connections

Notes on use
