MULTI CHANNEL AV RECEIVER

STR-DN1050/STR-DN850

Connecting the receiver to the network using a LAN cable (for wired LAN connections only)

The following illustration is an example configuration of a home network with the receiver and a server.

We recommend that you connect the server to the router with a wired connection.

Server

LAN cable (not supplied)

Router

Modem

Internet
