Sony STR-DN850 - Page 113

To Next Page

To Previous Page

Speakers

Amplifier/receiver made by Sony

HDMI cable (not supplied)

Note

To use this connection, set [Zone2 Out] in the HDMI Settings menu to [On].

Related Topic

Notes on connecting cables

Notes on use

4-488-938-11(1)

102
