MULTI CHANNEL AV RECEIVER

STR-DN1050/STR-DN850

How to connect speaker cables

Connect speaker cables as illustrated below.

Strip the jacket to 10 mm (13/32 in) at each end of the speaker cables.

Notes on use

4-488-938-11(1)

Help Guide

341
