– 144 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< JACK >
J401 1-779-795-11 JACK, PIN 1P (TV IN)
J402 1-779-796-11 JACK, PIN 2P (DVD/LD IN)
J403 1-779-796-11 JACK, PIN 2P (VIDEO 3 IN/OUT)
J404 1-779-796-11 JACK, PIN 2P (VIDEO 2 IN/OUT)
J405 1-779-796-11 JACK, PIN 2P (VIDEO 1 IN/OUT)
J406 1-779-796-11 JACK, PIN 2P (PROCESSOR IN/OUT)
J407 1-779-796-11 JACK, PIN 2P (MONITOR OUT 1,2)
< TRANSISTOR >
Q401 8-729-230-49 TRANSISTOR 2SC2712-YG
Q402 8-729-216-22 TRANSISTOR 2SA1162-G
Q403 8-729-230-49 TRANSISTOR 2SC2712-YG
Q404 8-729-216-22 TRANSISTOR 2SA1162-G
Q405 8-729-230-49 TRANSISTOR 2SC2712-YG
Q406 8-729-216-22 TRANSISTOR 2SA1162-G
Q407 8-729-230-49 TRANSISTOR 2SC2712-YG
Q408 8-729-216-22 TRANSISTOR 2SA1162-G
Q409 8-729-230-49 TRANSISTOR 2SC2712-YG
Q410 8-729-216-22 TRANSISTOR 2SA1162-G
Q411 8-729-216-22 TRANSISTOR 2SA1162-G
< RESISTOR >
R401 1-216-627-11 METAL CHIP 100 0.5% 1/10W
R402 1-216-627-11 METAL CHIP 100 0.5% 1/10W
R403 1-216-627-11 METAL CHIP 100 0.5% 1/10W
R404 1-216-627-11 METAL CHIP 100 0.5% 1/10W
R405 1-216-627-11 METAL CHIP 100 0.5% 1/10W
R406 1-216-627-11 METAL CHIP 100 0.5% 1/10W
R407 1-216-627-11 METAL CHIP 100 0.5% 1/10W
R408 1-216-627-11 METAL CHIP 100 0.5% 1/10W
R409 1-216-627-11 METAL CHIP 100 0.5% 1/10W
R410 1-208-462-41 RES,CHIP 10K 2% 1/10W
R411 1-208-462-41 RES,CHIP 10K 2% 1/10W
R412 1-208-345-11 RES,CHIP 15 2% 1/10W
R413 1-208-345-11 RES,CHIP 15 2% 1/10W
R414 1-216-677-11 METAL CHIP 12K 0.5% 1/10W
R415 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R416 1-216-677-11 METAL CHIP 12K 0.5% 1/10W
R417 1-216-635-11 METAL CHIP 220 0.5% 1/10W
R418 1-208-345-11 RES,CHIP 15 2% 1/10W
R419 1-208-345-11 RES,CHIP 15 2% 1/10W
R420 1-216-677-11 METAL CHIP 12K 0.5% 1/10W
R421 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R422 1-216-677-11 METAL CHIP 12K 0.5% 1/10W
R423 1-216-635-11 METAL CHIP 220 0.5% 1/10W
R424 1-208-345-11 RES,CHIP 15 2% 1/10W
R425 1-208-345-11 RES,CHIP 15 2% 1/10W
R426 1-216-677-11 METAL CHIP 12K 0.5% 1/10W
R427 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R428 1-216-677-11 METAL CHIP 12K 0.5% 1/10W
R429 1-216-635-11 METAL CHIP 220 0.5% 1/10W
R430 1-208-345-11 RES,CHIP 15 2% 1/10W
R431 1-208-345-11 RES,CHIP 15 2% 1/10W
R432 1-208-345-11 RES,CHIP 15 2% 1/10W
R433 1-208-345-11 RES,CHIP 15 2% 1/10W
R434 1-216-677-11 METAL CHIP 12K 0.5% 1/10W
R435 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R436 1-216-677-11 METAL CHIP 12K 0.5% 1/10W
R437 1-216-635-11 METAL CHIP 220 0.5% 1/10W
R438 1-208-755-11 RES,CHIP 75 2% 1/10W
R439 1-208-755-11 RES,CHIP 75 2% 1/10W
R440 1-208-755-11 RES,CHIP 75 2% 1/10W
R442 1-208-755-11 RES,CHIP 75 2% 1/10W
R444 1-208-755-11 RES,CHIP 75 2% 1/10W
R446 1-208-755-11 RES,CHIP 75 2% 1/10W
R448 1-208-755-11 RES,CHIP 75 2% 1/10W
R449 1-208-755-11 RES,CHIP 75 2% 1/10W
R452 1-208-526-41 RES,CHIP 47K 2% 1/10W
R453 1-208-526-41 RES,CHIP 47K 2% 1/10W
R454 1-208-526-41 RES,CHIP 47K 2% 1/10W
R455 1-216-619-11 METAL CHIP 47 0.5% 1/10W
R456 1-216-619-11 METAL CHIP 47 0.5% 1/10W
R457 1-216-619-11 METAL CHIP 47 0.5% 1/10W
R458 1-216-619-11 METAL CHIP 47 0.5% 1/10W
R459 1-216-619-11 METAL CHIP 47 0.5% 1/10W
R460 1-216-677-11 METAL CHIP 12K 0.5% 1/10W
R461 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R462 1-216-677-11 METAL CHIP 12K 0.5% 1/10W
R463 1-216-635-11 METAL CHIP 220 0.5% 1/10W
R464 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R465 1-216-635-11 METAL CHIP 220 0.5% 1/10W
**************************************************************
* 1-671-185-11 VOLUME BOARD
************
< CAPACITOR >
C914 1-104-664-11 ELECT 47uF 20% 25V
< CONNECTOR >
* CN952 1-568-954-11 PIN, CONNECTOR 5P
< VARIABLE RESISTOR >
RV901 1-225-680-11 RES, VAR, CARBON (WITH M) 10K
(MASTER VOLUME)
**************************************************************
MISCELLANEOUS
*************
! 7 1-559-479-11 CORD, POWER (US,CND)
! 7 1-575-953-11 CORD, POWER (EXCEPT US,CND)
72 1-765-344-11 WIRE (FLAT TYPE)(23 CORE)(160mm)
(FORMER TYPE)
72 1-773-216-11 WIRE (FLAT TYPE) (25 CORE) (NEW TYPE)
104 1-783-943-11 WIRE, FLAT TYPE (7 CORE)
108 1-773-006-11 WIRE (FLAT TYPE)(15 CORE)
109 1-769-973-11 WIRE (FLAT TYPE)(13 CORE)
FL901 1-517-962-11 INDICATOR TUBE, FLUORESCENT
! T001 1-433-482-11 TRANSFORMER, POWER (US,CND)
! T001 1-433-483-11 TRANSFORMER, POWER (EXCEPT US,CND)
**************************************************************
VOLUMEVIDEO
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Ver 1.1 2002.08
