4-4. PRINTED WIRING BOARD – VIDEO SECTION –
• See page 12 for Circuit Boards Location.
Ref. No. Location
• Semiconductor
Location
IC401 B-7
IC402 B-5
IC403 B-6
IC404 C-2
Q401 B-3
Q402 B-3
Q403 B-4
Q404 B-4
Q405 B-3
Q406 B-3
Q407 B-2
Q408 B-2
Q409 B-1
Q410 B-1
Q411 C-3
(Page 50)
