– 140 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
D110 8-719-025-03 DIODE RBA-402-SL
D111 8-719-025-29 DIODE 02CZ5.1-TE85L
D112 8-719-820-05 DIODE 1SS181
D113 8-719-820-05 DIODE 1SS181
D114 8-719-820-05 DIODE 1SS181
D115 8-719-820-05 DIODE 1SS181
D116 8-719-820-05 DIODE 1SS181
D117 8-719-820-05 DIODE 1SS181
D118 8-719-820-05 DIODE 1SS181
D119 8-719-820-05 DIODE 1SS181
D120 8-719-820-05 DIODE 1SS181
D121 8-719-025-33 DIODE 02CZ6.2-TE85L
D122 8-719-820-05 DIODE 1SS181
D123 8-719-820-05 DIODE 1SS181
D124 8-719-820-05 DIODE 1SS181
D125 8-719-800-76 DIODE 1SS226
D126 8-719-800-76 DIODE 1SS226
D127 8-719-820-05 DIODE 1SS181
D128 8-719-820-05 DIODE 1SS181
< GROUND TERMINAL >
E101 1-537-770-21 TERMINAL BOARD, GROUND
E103 1-537-770-21 TERMINAL BOARD, GROUND
< IC >
IC101 8-759-636-55 IC M5218AFP
IC102 8-759-632-07 IC M5237L
IC103 8-759-604-86 IC M5F7807L
IC104 8-759-604-90 IC M5F7907L
IC105 8-759-450-47 IC BA05T
IC106 8-759-245-79 IC TA79005S
IC107 8-759-604-87 IC M5F7818L
IC108 8-759-636-55 IC M5218AFP
IC109 8-759-604-91 IC M5F7918L
< PHOTO INTERUPTER >
PH101 8-719-936-96 PHOTO COUPLER PC817-B
PH102 8-719-936-96 PHOTO COUPLER PC817-B
< TRANSISTOR >
Q101 8-729-216-22 TRANSISTOR 2SA1162-G
Q102 8-729-230-49 TRANSISTOR 2SC2712-YG
Q103 8-729-230-49 TRANSISTOR 2SC2712-YG
Q104 8-729-230-49 TRANSISTOR 2SC2712-YG
Q105 8-729-216-22 TRANSISTOR 2SA1162-G
Q106 8-729-209-15 TRANSISTOR 2SD2012
Q107 8-729-141-83 TRANSISTOR 2SB1094-LK
Q108 8-729-142-50 TRANSISTOR 2SD1616-X
Q109 8-729-230-49 TRANSISTOR 2SC2712-YG
Q110 8-729-140-05 TRANSISTOR 2SB1116A-K
Q111 8-729-209-15 TRANSISTOR 2SD2012
Q112 8-729-141-83 TRANSISTOR 2SB1094-LK
Q113 8-729-230-49 TRANSISTOR 2SC2712-YG
Q114 8-729-216-22 TRANSISTOR 2SA1162-G
Q115 8-729-140-05 TRANSISTOR 2SB1116-K
Q116 8-729-142-50 TRANSISTOR 2SD1616-X
Q117 8-729-141-83 TRANSISTOR 2SB1094-LK
Q118 8-729-424-08 TRANSISTOR UN2111
Q119 8-729-141-83 TRANSISTOR 2SB1094-LK
Q120 8-729-141-83 TRANSISTOR 2SB1094-LK
Q121 8-729-141-83 TRANSISTOR 2SB1094-LK
Q122 8-729-141-83 TRANSISTOR 2SB1094-LK
Q123 8-729-018-59 TRANSISTOR 2SB1375(LB SONY)
Q124 8-729-018-60 TRANSISTOR 2SD2012-LC
Q125 8-729-018-59 TRANSISTOR 2SB1375(LB SONY)
Q126 8-729-018-60 TRANSISTOR 2SD2012-LC
Q127 8-729-230-49 TRANSISTOR 2SC2712-YG
< RESISTOR >
R101 1-208-445-41 RES,CHIP 2.2K 2% 1/10W
R102 1-208-462-41 RES,CHIP 10K 2% 1/10W
R103 1-208-462-41 RES,CHIP 10K 2% 1/10W
R104 1-208-445-41 RES,CHIP 2.2K 2% 1/10W
R105 1-208-445-41 RES,CHIP 2.2K 2% 1/10W
R106 1-208-445-41 RES,CHIP 2.2K 2% 1/10W
R107 1-208-518-41 RES,CHIP 22K 2% 1/10W
R108 1-208-772-11 RES,CHIP 390 2% 1/10W
R109 1-208-772-11 RES,CHIP 390 2% 1/10W
R110 1-208-462-41 RES,CHIP 10K 2% 1/10W
R111 1-208-462-41 RES,CHIP 10K 2% 1/10W
R112 1-208-526-41 RES,CHIP 47K 2% 1/10W
R113 1-208-462-41 RES,CHIP 10K 2% 1/10W
R114 1-259-995-11 RES,CHIP 1K 2% 1/8W
R115 1-259-995-11 RES,CHIP 1K 2% 1/8W
R116 1-208-445-41 RES,CHIP 2.2K 2% 1/10W
R117 1-208-462-41 RES,CHIP 10K 2% 1/10W
R118 1-259-930-11 RES,CHIP 4.3K 2% 1/8W
R119 1-259-995-11 RES,CHIP 1K 2% 1/8W
R120 1-259-999-11 RES,CHIP 2.2K 2% 1/8W
R121 1-259-995-11 RES,CHIP 1K 2% 1/8W
R122 1-259-999-11 RES,CHIP 2.2K 2% 1/8W
R123 1-259-930-11 RES,CHIP 4.3K 2% 1/8W
R124 1-208-453-41 RES,CHIP 4.7K 2% 1/10W
R125 1-208-462-41 RES,CHIP 10K 2% 1/10W
R126 1-208-462-41 RES,CHIP 10K 2% 1/10W
! R127 1-249-451-11 CARBON 2.2 5% 1/4W
! R128 1-249-451-11 CARBON 2.2 5% 1/4W
! R129 1-249-451-11 CARBON 2.2 5% 1/4W
! R130 1-249-451-11 CARBON 2.2 5% 1/4W
R131 1-208-462-41 RES,CHIP 10K 2% 1/10W
R132 1-208-437-41 RES,CHIP 1K 2% 1/10W
R133 1-208-437-41 RES,CHIP 1K 2% 1/10W
R134 1-208-437-41 RES,CHIP 1K 2% 1/10W
R135 1-216-671-11 METAL CHIP 6.8K 0.5% 1/10W
R136 1-208-462-41 RES,CHIP 10K 2% 1/10W
R137 1-208-445-41 RES,CHIP 2.2K 2% 1/10W
R138 1-208-774-11 RES,CHIP 470 2% 1/10W
R139 1-208-462-41 RES,CHIP 10K 2% 1/10W
R140 1-208-774-11 RES,CHIP 470 2% 1/10W
R141 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R142 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
! R143 1-217-153-00 METAL 0.47 10% 2W
! R144 1-217-153-00 METAL 0.47 10% 2W
POWER
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
