– 141 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
! R145 1-217-153-00 METAL 0.47 10% 2W
! R146 1-217-153-00 METAL 0.47 10% 2W
R150 1-208-462-41 RES,CHIP 10K 2% 1/10W
R151 1-208-462-41 RES,CHIP 10K 2% 1/10W
R152 1-208-445-41 RES,CHIP 2.2K 2% 1/10W
R153 1-208-550-41 RES,CHIP 470K 2% 1/10W
R154 1-208-462-41 RES,CHIP 10K 2% 1/10W
R155 1-208-462-41 RES,CHIP 10K 2% 1/10W
R156 1-208-462-41 RES,CHIP 10K 2% 1/10W
R157 1-260-070-51 CARBON 3.3 5% 1/2W
R158 1-208-462-41 RES,CHIP 10K 2% 1/10W
R160 1-208-437-41 RES,CHIP 1K 2% 1/10W
R161 1-208-437-41 RES,CHIP 1K 2% 1/10W
R162 1-208-437-41 RES,CHIP 1K 2% 1/10W
R163 1-208-437-41 RES,CHIP 1K 2% 1/10W
R164 1-208-437-41 RES,CHIP 1K 2% 1/10W
R165 1-208-437-41 RES,CHIP 1K 2% 1/10W
R166 1-208-453-41 RES,CHIP 4.7K 2% 1/10W
R167 1-208-526-41 RES,CHIP 47K 2% 1/10W
R168 1-208-437-41 METAL,CHIP 1K 2% 1/10W
R169 1-208-437-41 METAL,CHIP 1K 2% 1/10W
< THERMISTOR >
THP159 1-806-882-11 THERMISTOR
**************************************************************
* 1-671-189-11 REMOCON RAY-CATCHER BOARD
*************************
< CAPACITOR >
C901 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
< IC >
IC908 8-759-459-83 IC NJL55H400A
**************************************************************
* A-4417-101-A (S) VIDEO BOARD, COMPLETE
*************************
* 1-535-303-00 WIRE, JUMPER
4-213-456-01 SPACER (30)
< CAPACITOR >
C201 1-119-799-11 ELECT 47uF 20% 25V
C202 1-119-799-11 ELECT 47uF 20% 25V
C203 1-119-799-11 ELECT 47uF 20% 25V
C204 1-119-799-11 ELECT 47uF 20% 25V
C205 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C206 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C207 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C208 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C209 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C210 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C211 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C212 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C213 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C214 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C215 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C216 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C217 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C218 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C219 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C220 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C221 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C222 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C223 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C224 1-119-825-41 ELECT 22uF 20% 50V
C225 1-119-824-31 ELECT 10uF 20% 50V
C226 1-119-824-31 ELECT 10uF 20% 50V
C227 1-119-824-31 ELECT 10uF 20% 50V
C228 1-119-824-31 ELECT 10uF 20% 50V
C229 1-119-824-31 ELECT 10uF 20% 50V
C230 1-119-824-31 ELECT 10uF 20% 50V
C231 1-119-824-31 ELECT 10uF 20% 50V
C232 1-119-824-31 ELECT 10uF 20% 50V
C233 1-119-824-31 ELECT 10uF 20% 50V
C234 1-119-824-31 ELECT 10uF 20% 50V
C235 1-119-799-11 ELECT 47uF 20% 25V
C236 1-119-799-11 ELECT 47uF 20% 25V
C237 1-119-799-11 ELECT 47uF 20% 25V
C238 1-119-799-11 ELECT 47uF 20% 25V
C239 1-119-799-11 ELECT 47uF 20% 25V
C240 1-119-799-11 ELECT 47uF 20% 25V
C241 1-119-799-11 ELECT 47uF 20% 25V
C242 1-119-799-11 ELECT 47uF 20% 25V
C243 1-136-165-00 FILM 0.1uF 5% 50V
C244 1-136-165-00 FILM 0.1uF 5% 50V
C245 1-136-165-00 FILM 0.1uF 5% 50V
C246 1-136-165-00 FILM 0.1uF 5% 50V
C247 1-136-165-00 FILM 0.1uF 5% 50V
C248 1-136-165-00 FILM 0.1uF 5% 50V
C249 1-119-820-31 ELECT 1uF 20% 50V
C250 1-119-824-31 ELECT 10uF 20% 50V
C251 1-119-824-31 ELECT 10uF 20% 50V
< CONNECTOR >
* CN201 1-568-856-11 SOCKET, CONNECTOR 13P
* CN202 1-568-858-11 SOCKET, CONNECTOR 15P
< IC >
IC201 8-759-000-47 IC MC14051BCP
IC202 8-759-000-47 IC MC14051BCP
IC203 8-759-000-47 IC MC14051BCP
IC204 8-759-140-53 IC UPD4053BC
IC205 8-759-261-99 IC MC14576CP
IC206 8-759-261-99 IC MC14576CP
IC207 8-759-000-49 IC MC14066BCP
IC208 8-759-000-49 IC MC14066BCP
IC209 8-759-032-59 IC MC74HC595AF
< JACK >
J201 1-779-800-11 TERMINAL, S (TV IN)
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
