– 139 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
* 1-671-190-11 LUMINOUS BOARD
**************
< CONNECTOR >
CN954 1-506-468-11 PIN, CONNECTOR 3P
< DIODE >
D918 8-719-058-98 DIODE SID1003BQ-LF57 (CUSTOM)
D919 8-719-058-98 DIODE SID1003BQ-LF57 (LEVEL)
D920 8-719-058-98 DIODE SID1003BQ-LF57 (MODE +)
D921 8-719-058-98 DIODE SID1003BQ-LF57 (MODE –)
D922 8-719-058-98 DIODE SID1003BQ-LF57 (SP SET UP)
< RESISTOR >
! R992 1-215-857-11 METAL OXIDE 10 5% 1W F
**************************************************************
* 1-671-186-11 OUTLET BOARD
************
< CONNECTOR >
CN004 1-564-321-00 PIN, CONNECTOR 2P
CN005 1-506-468-11 PIN, CONNECTOR 3P
< DIODE >
D001 8-719-016-74 DIODE 1SS352
< JACK >
J001 1-251-718-11 OUTLET (2 GANG), AC (US,CND)
J001 1-785-285-11 OUTLET, AC (1P)(EXCEPT US,CND)
< RELAY >
! RY001 1-755-018-11 RELAY
**************************************************************
* A-4417-104-A POWER BOARD, COMPLETE (US,CND)
*********************
* A-4417-110-A POWER BOARD, COMPLETE (EXCEPT US,CND)
*********************
* 1-535-303-00 WIRE, JUMPER
2-389-320-01 CUSHION
4-211-649-01 SCREW (+BV 3X6 B)
4-213-455-01 HEAT SINK
4-974-510-01 SCREW (+BV 3X8 B)
* 4-990-797-01 HOLDER (FL)
< CAPACITOR >
C101 1-163-141-00 CERAMIC CHIP 1000PF 5% 50V
C106 1-163-141-00 CERAMIC CHIP 1000PF 5% 50V
C107 1-163-141-00 CERAMIC CHIP 1000PF 5% 50V
C110 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C111 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C112 1-126-960-11 ELECT 1uF 20% 50V
C115 1-119-800-21 ELECT 100uF 20% 25V
C116 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C117 1-163-093-00 CERAMIC CHIP 10PF 5% 50V
C118 1-119-840-21 ELECT 470uF 20% 63V
C119 1-163-093-00 CERAMIC CHIP 10PF 5% 50V
C120 1-126-955-11 ELECT 4700uF 20% 35V
C121 1-117-783-11 ELECT 13000uF 20% 16V
C122 1-119-800-21 ELECT 100uF 20% 25V
C123 1-119-840-21 ELECT 470uF 20% 63V
C124 1-126-955-11 ELECT 4700uF 20% 35V
C125 1-117-783-11 ELECT 13000uF 20% 16V
C126 1-117-783-11 ELECT 13000uF 20% 16V
C127 1-117-783-11 ELECT 13000uF 20% 16V
C128 1-119-830-11 ELECT 330uF 20% 25V
C129 1-126-964-11 ELECT 10uF 20% 50V
C130 1-119-830-11 ELECT 330uF 20% 25V
C131 1-126-927-11 ELECT 2200uF 20% 10V
C133 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C134 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C135 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C136 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C137 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C138 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C139 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C140 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C141 1-126-924-11 ELECT 330uF 20% 10V
C142 1-126-924-11 ELECT 330uF 20% 10V
C143 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C144 1-126-964-11 ELECT 10uF 20% 50V
C145 1-126-941-11 ELECT 470uF 20% 25V
C146 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C147 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C148 1-126-941-11 ELECT 470uF 20% 25V
C149 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C150 1-164-222-11 CERAMIC CHIP 0.22uF 25V
C151 1-136-169-00 FILM 0.22uF 5% 50V
C152 1-136-169-00 FILM 0.22uF 5% 50V
C153 1-164-222-11 CERAMIC CHIP 0.22uF 25V
C154 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C155 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
* CN102 1-564-243-11 PIN, CONNECTOR 6P
* CN103 1-564-104-00 PIN, CONNECTOR (B3P-VH) 3P
* CN104 1-564-104-00 PIN, CONNECTOR (B3P-VH) 3P
* CN105 1-564-241-11 PIN, CONNECTOR (B4P-VH) 4P
CN106 1-691-771-11 PLUG (MICRO CONNECTOR) 9P
< DIODE >
D101 8-719-800-76 DIODE 1SS226
D102 8-719-025-37 DIODE 02CZ9.1-TE85L
D103 8-719-025-37 DIODE 02CZ9.1-TE85L
D104 8-719-800-76 DIODE 1SS226
D105 8-719-820-05 DIODE 1SS181
D106 8-719-025-29 DIODE 02CZ5.1-TE85L
D107 8-719-060-53 DIODE RBV-2506
D108 8-719-820-05 DIODE 1SS181
D109 8-719-820-05 DIODE 1SS181
LUMINOUS
OUTLET
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
