24
TA-E9000ES
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
POWER
<CAPACITOR>
C110 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C111 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C112 1-126-960-11 ELECT 1uF 20% 50V
C115 1-119-800-21 ELECT 100uF 20% 25V
C116 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C117 1-163-093-00 CERAMIC CHIP 10PF 5% 50V
C118 1-119-840-21 ELECT 470uF 20% 63V
C119 1-163-093-00 CERAMIC CHIP 10PF 5% 50V
C120 1-126-955-11 ELECT 4700uF 20% 35V
C121 1-117-783-11 ELECT 13000uF 20% 16V
C122 1-119-800-21 ELECT 100uF 20% 25V
C123 1-119-840-21 ELECT 470uF 20% 63V
C124 1-126-955-11 ELECT 4700uF 20% 35V
C125 1-117-783-11 ELECT 13000uF 20% 16V
C126 1-117-783-11 ELECT 13000uF 20% 16V
C127 1-117-783-11 ELECT 13000uF 20% 16V
C128 1-119-830-11 ELECT 330uF 20% 25V
C129 1-126-964-11 ELECT 10uF 20% 50V
C130 1-119-830-11 ELECT 330uF 20% 25V
C131 1-126-927-11 ELECT 2200uF 20% 10V
C133 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C134 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C136 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C137 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C138 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C140 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C141 1-126-924-11 ELECT 330uF 20% 10V
C142 1-126-924-11 ELECT 330uF 20% 10V
C144 1-126-964-11 ELECT 10uF 20% 50V
C145 1-119-800-21 ELECT 100uF 20% 25V
C146 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C148 1-119-800-21 ELECT 100uF 20% 25V
C149 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C150 1-164-222-91 CERAMIC CHIP 0.22uF 25V
C151 1-136-169-00 MYLAR 0.22uF 5% 50V
C152 1-136-169-00 MYLAR 0.22uF 5% 50V
C153 1-164-222-91 CERAMIC CHIP 0.22uF 25V
C154 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C155 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C156 1-163-009-91 CERAMIC CHIP 0.001uF 10% 50V
C157 1-119-824-31 ELECT 10uF 20% 50V
C158 1-119-824-31 ELECT 10uF 20% 50V
<CONNECTOR>
* CN102 1-564-243-11 PIN, CONNECTOR(3.96MM PITCH)6P
* CN103 1-564-104-00 PIN, CONNECTOR(3.96MM PITCH)3P
* CN104 1-564-104-00 PIN, CONNECTOR(3.96MM PITCH)3P
* CN105 1-564-241-11 PIN, CONNECTOR(3.96MM PITCH)4P
CN106 1-691-771-11 PLUG (MICRO CONNECTOR) 9P
<DIODE>
D101 8-719-800-76 DIODE 1SS226
D102 8-719-025-37 DIODE 02CZ9.1-TE85L
D103 8-719-025-37 DIODE 02CZ9.1-TE85L
D104 8-719-800-76 DIODE 1SS226
D105 8-719-820-05 DIODE 1SS181
D106 8-719-025-29 DIODE 02CZ5.1-TE85L
D107 8-719-060-53 DIODE RBV-2506
D108 8-719-820-05 DIODE 1SS181
D109 8-719-820-05 DIODE 1SS181
D110 8-719-025-03 DIODE RBA-402-SL
D111 8-719-025-29 DIODE 02CZ5.1-TE85L
D112 8-719-820-05 DIODE 1SS181
D113 8-719-820-05 DIODE 1SS181
D114 8-719-820-05 DIODE 1SS181
D115 8-719-820-05 DIODE 1SS181
D116 8-719-820-05 DIODE 1SS181
D117 8-719-820-05 DIODE 1SS181
D118 8-719-820-05 DIODE 1SS181
D119 8-719-820-05 DIODE 1SS181
D120 8-719-820-05 DIODE 1SS181
D121 8-719-025-33 DIODE 02CZ6.2-TE85L
D122 8-719-820-05 DIODE 1SS181
D123 8-719-820-05 DIODE 1SS181
D124 8-719-820-05 DIODE 1SS181
D125 8-719-800-76 DIODE 1SS226
D126 8-719-800-76 DIODE 1SS226
D127 8-719-820-05 DIODE 1SS181
D128 8-719-820-05 DIODE 1SS181
<GROUND TERMINAL>
E101 1-537-770-21 TERMINAL BOARD, GROUND
E102 1-537-770-21 TERMINAL BOARD, GROUND
E103 1-537-770-21 TERMINAL BOARD, GROUND
<IC>
IC101 8-759-636-55 IC M5218AFP-T1
IC102 8-759-632-07 IC M5237L-700A
IC103 8-759-604-86 IC M5F7807L
IC104 8-759-604-90 IC M5F7907L
IC105 8-759-450-47 IC BA05T
IC106 8-759-245-79 IC M5F7905L
IC107 8-759-604-87 IC M5F7818L
IC108 8-759-636-55 IC M5218AFP-T1
IC109 8-759-604-91 IC M5F7918L
<PHOTO INTERUPTER>
PH101 8-719-936-96 PHOTO COUPLER PC817-B
PH102 8-719-936-96 PHOTO COUPLER PC817-B
<TRANSISTOR>
Q101 8-729-216-22 TRANSISTOR 2SA1162-G
Q102 8-729-230-49 TRANSISTOR 2SC2712-YG
Q103 8-729-230-49 TRANSISTOR 2SC2712-YG
Q104 8-729-230-49 TRANSISTOR 2SC2712-YG
Q105 8-729-216-22 TRANSISTOR 2SA1162-G
Q106 8-729-209-15 TRANSISTOR 2SD2012
Q107 8-729-209-60 TRANSISTOR 2SB1375
Q108 8-729-111-29 TRANSISTOR 2SD1616A-K
Q109 8-729-230-49 TRANSISTOR 2SC2712-YG
Q110 8-729-140-05 TRANSISTOR 2SB1116A-K
Q111 8-729-209-15 TRANSISTOR 2SD2012
Q112 8-729-209-60 TRANSISTOR 2SB1375
Q113 8-729-230-49 TRANSISTOR 2SC2712-YG
