– 123 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C822 1-119-841-11 ELECT 1000uF 20% 63V
C823 1-119-800-11 ELECT 100uF 20% 25V
C824 1-119-800-11 ELECT 100uF 20% 25V
C825 1-119-800-11 ELECT 100uF 20% 25V
C826 1-119-800-11 ELECT 100uF 20% 25V
C830 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C831 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CN501 1-691-769-11 PLUG (MICRO CONNECTOR) 7P
* CN503 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
CN504 1-691-772-21 PLUG (MICRO CONNECTOR)10P
CN505 1-691-772-11 PLUG (MICRO CONNECTOR) 10P
* CN507 1-568-832-11 SOCKET, CONNECTOR 13P
* CN508 1-568-936-11 PIN, CONNECTOR 9P
CN509 1-564-506-11 PLUG, CONNECTOR 3P
CN510 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
CN511 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
< DIODE >
D501 8-719-016-74 DIODE 1SS352
D502 8-719-016-74 DIODE 1SS352
D503 8-719-016-74 DIODE 1SS352
D504 8-719-016-74 DIODE 1SS352
D505 8-719-016-74 DIODE 1SS352
D506 8-719-016-74 DIODE 1SS352
D507 8-719-016-74 DIODE 1SS352
D508 8-719-016-74 DIODE 1SS352
D509 8-719-016-74 DIODE 1SS352
< HEAT SINK >
* HS527 3-309-144-21 HEAT SINK
* HS528 3-309-144-21 HEAT SINK
* HS529 3-309-144-21 HEAT SINK
* HS530 3-309-144-21 HEAT SINK
< IC >
IC502 8-759-805-14 IC LC7822
IC503 8-759-805-14 IC LC7822
IC504 8-759-711-85 IC NJM4580E-D
IC506 8-759-711-85 IC NJM4580E-D
IC507 8-759-711-85 IC NJM4580E-D
IC508 8-759-711-85 IC NJM4580E-D
IC511 8-759-711-85 IC NJM4580E-D
IC512 8-759-711-85 IC NJM4580E-D
IC513 8-759-296-74 IC AD712JR
IC514 8-759-711-85 IC NJM4580E-D
IC515 8-759-711-85 IC NJM4580E-D
IC516 8-759-296-74 IC AD712JR
IC517 8-759-711-85 IC NJM4580E-D
IC518 8-759-711-85 IC NJM4580E-D
IC519 8-759-296-74 IC AD712JR
IC520 8-759-711-85 IC NJM4580E-D
IC521 8-759-711-85 IC NJM4580E-D
IC522 8-759-711-85 IC NJM4580E-D
IC523 8-759-711-85 IC NJM4580E-D
IC524 8-759-032-59 IC MC74HC595AF
IC525 8-759-032-59 IC MC74HC595AF
IC526 8-759-032-59 IC MC74HC595AF
IC527 8-759-604-39 IC M5F78M12
IC528 8-759-604-45 IC M5F79M12
IC529 8-759-604-35 IC M5F78M05L
IC530 8-759-701-65 IC NJM79M05FA
IC531 8-759-711-85 IC NJM4580E-D
IC532 8-759-711-85 IC NJM4580E-D
IC533 8-759-711-85 IC NJM4580E-D
IC536 8-759-630-34 IC M5278L05M
< JACK >
J501 1-778-517-11 JACK, PIN 6P (CD/TUNER/PHONO IN)
J503 1-784-934-11 JACK, PIN 4P (MD/DAT IN/OUT)
J504 1-784-934-11 JACK, PIN 4P (TAPE IN/OUT)
J507 1-778-517-11 JACK, PIN 6P (LD/DVD IN.TV OUT)
J509 1-784-934-11 JACK, PIN 4P (VIDEO 3 IN/OUT)
J510 1-784-934-11 JACK, PIN 4P (VIDEO 2 IN/OUT)
J511 1-784-934-11 JACK, PIN 4P (VIDEO 1 IN/OUT)
J512 1-784-934-11 JACK, PIN 4P (AUDIO PREOUT REAR/FRONT)
J513 1-785-286-11 JACK, PIN 4P
(AUDIO PREOUT WOOFER/CENTER)
< JUMPER RESISTOR >
JR501 1-216-295-91 SHORT 0
JR502 1-216-295-91 SHORT 0
JR503 1-216-295-91 SHORT 0
JR504 1-216-295-91 SHORT 0
JR601 1-216-295-91 SHORT 0
JR602 1-216-295-91 SHORT 0
JR603 1-216-295-91 SHORT 0
JR604 1-216-295-91 SHORT 0
JR802 1-216-296-91 SHORT 0
JR803 1-216-296-91 SHORT 0
JR804 1-216-296-91 SHORT 0
< TRANSISTOR >
Q501 8-729-107-46 TRANSISTOR 2SC3624A-L15
Q502 8-729-107-46 TRANSISTOR 2SC3624A-L15
Q503 8-729-107-46 TRANSISTOR 2SC3624A-L15
Q504 8-729-107-46 TRANSISTOR 2SC3624A-L15
Q505 8-729-107-46 TRANSISTOR 2SC3624A-L15
Q506 8-729-107-46 TRANSISTOR 2SC3624A-L15
Q507 8-729-107-46 TRANSISTOR 2SC3624A-L15
Q508 8-729-107-46 TRANSISTOR 2SC3624A-L15
Q509 8-729-107-46 TRANSISTOR 2SC3624A-L15
Q510 8-729-107-46 TRANSISTOR 2SC3624A-L15
Q511 8-729-107-46 TRANSISTOR 2SC3624A-L15
Q512 8-729-107-46 TRANSISTOR 2SC3624A-L15
Q513 8-729-107-46 TRANSISTOR 2SC3624A-L15
Q514 8-729-107-46 TRANSISTOR 2SC3624A-L15
Q515 8-729-107-46 TRANSISTOR 2SC3624A-L15
Q516 8-729-107-46 TRANSISTOR 2SC3624A-L15
Q517 8-729-107-46 TRANSISTOR 2SC3624A-L15
Q518 8-729-107-46 TRANSISTOR 2SC3624A-L15
Q519 8-729-424-08 TRANSISTOR UN2111
Q520 8-729-421-19 TRANSISTOR UN2213
ANALOG
