– 127 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R862 1-216-627-11 METAL CHIP 100 0.5% 1/10W
R863 1-216-627-11 METAL CHIP 100 0.5% 1/10W
R864 1-208-462-41 RES,CHIP 10K 2% 1/10W
R865 1-208-462-41 RES,CHIP 10K 2% 1/10W
R871 1-260-017-91 CARBON MELF 56K 2% 1/8W
R872 1-260-017-91 CARBON MELF 56K 2% 1/8W
R873 1-260-017-91 CARBON MELF 56K 2% 1/8W
R874 1-260-017-91 CARBON MELF 56K 2% 1/8W
< VARIABLE RESISTOR >
RV501 1-238-605-31 RES, VR, CABON 470K (OFFSET L)
RV502 1-238-605-31 RES, VR, CABON 470K (OFFSET R)
RV503 1-238-605-31 RES, VR, CABON 470K (OFFSET C)
RV504 1-238-605-31 RES, VR, CABON 470K (OFFSET SW)
RV505 1-238-605-31 RES, VR, CABON 470K (OFFSET SL)
RV506 1-238-605-31 RES, VR, CABON 470K (OFFSET SR)
< RELAY >
RY501 1-755-061-11 RELAY
RY502 1-755-061-11 RELAY
RY503 1-755-061-11 RELAY
RY504 1-755-061-11 RELAY
RY505 1-755-061-11 RELAY
RY506 1-755-061-11 RELAY
RY507 1-755-061-11 RELAY
RY508 1-755-061-11 RELAY
RY509 1-755-061-11 RELAY
**************************************************************
* 1-671-196-11 CAPACITOR BOARD
****************
< CAPACITOR >
C051 1-119-805-21 ELECT 2200uF 20% 25V
C052 1-119-805-21 ELECT 2200uF 20% 25V
C053 1-127-566-11 ELECT 6800uF 20% 35V
C054 1-127-566-11 ELECT 6800uF 20% 35V
C055 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C056 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C057 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C058 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C059 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C060 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C061 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C062 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C063 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C064 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C065 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C066 1-136-177-00 FILM 1uF 5% 50V
C067 1-136-165-00 FILM 0.1uF 5% 50V
< CONNECTOR >
* CN051 1-564-242-00 CONNECTOR 6P
* CN053 1-564-242-00 PIN, CONNECTOR 5P
< DIODE >
D051 8-719-302-38 DIODE RBV-602-01
D052 8-719-302-38 DIODE RBV-602-01
< GROUND PLATE >
EP051 1-537-770-21 TERMINAL BOARD, GROUND
< FUSE >
! F051 1-532-505-51 FUSE,TIMELAG +5AL/250V (EXCEPT US,CND)
! F051 1-576-109-11 FUSE 5A/125V(US,CND)
! F052 1-532-505-51 FUSE,TIMELAG +5AL/250V (EXCEPT US,CND)
! F052 1-576-109-11 FUSE 5A/125V(US,CND)
< FUSE HOLDER >
FH005 1-533-293-11 FUSE HOLDER
FH006 1-533-293-11 FUSE HOLDER
FH007 1-533-293-11 FUSE HOLDER
FH008 1-533-293-11 FUSE HOLDER
< RESISTOR >
R051 1-212-865-00 FUS RES 22 5% 1/4W
**************************************************************
* 1-670-916-11 CLOCK BOARD
***********
< CAPACITOR >
C7001 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN7001 1-691-173-11 CONNECTOR (BOARD TO BOARD) 3P
CN7002 1-691-173-11 CONNECTOR (BOARD TO BOARD) 3P
CN7003 1-691-173-11 CONNECTOR (BOARD TO BOARD) 3P
< INDUCTOR >
R7003 1-414-231-11 INDUCTOR, FERRITE BEAD
< VIBRATOR >
X7001 1-767-433-11 OSCILLATOR, CRYSTAL (49.152MHz)
**************************************************************
* A-4417-106-A DIGITAL BOARD, COMPLETE (US,CND)
***********************
* A-4419-255-A DIGITAL BOARD, COMPLETE (EXCEPT US,CND)
***********************
1-216-121-91 RES,CHIP 1M 5% 1/10W
4-974-510-01 SCREW (+BV 3X8 B)
< CAPACITOR >
C1001 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C1002 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C1003 1-119-792-21 ELECT 470uF 20% 16V
C1004 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C1005 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
CAPACITOR CLOCK
ANALOG
DIGITAL
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
