72
System Configuration Menu
Chapter 3 Menu
Network
SDCP Port No Sets the SDCP port number.
Set to 53434 to 53534. [53484]
SDAP Port No Sets the SDAP port number.
Set to 53812 to 53912. [53862]
SDAP Broadcast Sets whether or not to issue the SDAP (Disable or [Enable]).
SDAP Broadcast Period Sets the period (seconds) to issue the SDAP.
Set to 05 to 30. [15]
Acceptable IP Address Sets the IP address to connect.
When the item is selected, you can set IP1 to IP4.
Cancel: Cancels the changed or confirmed setting.
Confirm: Saves the changed or confirmed setting.
Reset Protocol Setting Resets the protocol setting.
When the item is selected, the following message appears.
Are you sure?
OK: To reset data, press the ENTER (Ent) button.
Cancel: To cancel, press the MENU button.
Parallel Remote Sets the parallel remote function.
Parallel Remote Selects whether or not to use the parallel remote functions. ([Off] or On)
1 Pin to 8 Pin Assigns the function to each pin of the PARALLEL REMOTE connector when Parallel Remote
is set to On.
The default assignment of functions is as follows:
1 Pin: [CH01]
2 Pin: [CH02]
3 Pin: [External Sync]
4 Pin: [Mono]
5 Pin: [Marker]
6 Pin: [unused]
7 Pin: [unused]
8 Pin: [Tally]
You can change the assignment to the following functions for pins 1 to 8.
The functions shown with item name only are the same as those assigned to the function
buttons on the controller.
For details on these functions, see “Function Key” (page 82) of the Controller menu.
Parallel Remote (1/5)
CH01 to 30: Selects a channel number. Enter the desired channel number with the
numeric buttons.
----: Unused
Under Scan,
1)
Over Scan,
1)
Native Scan, 16:9, H Delay, V Delay, External Sync,
Comb
1) The scan mode is set to Normal Scan when Under Scan or Over Scan is off.
Parallel Remote (2/5)
Aperture, Mono, Blue Only, R Off, G Off, B Off, Chroma Up, Interlace
Tally: The function to turn on the tally lamp
Power Off: The monitor power function
Parallel Remote (3/5)
Marker, Aspect Marker, Area Marker 1, Area Marker 2, Center Marker, Aspect
Marker-Line, Aspect Blanking-Half, Aspect Blanking-Black
Parallel Remote (4/5)
Side by Side, Wipe, Butterfly, Blending, Error Notify Clear, Audio Level Meter, ALM
Hold Reset, Time Code
Parallel Remote (5/5)
Difference, Checkerboard, L/R Switch, Horopter Check, Flip H
For the pin assignment, see “PARALLEL REMOTE connector” in Location and Function of
Parts on page 20.
Menu Function and operation ([ ]: factory setting)
