73
System Configuration Menu
Chapter 3 Menu
Power Sets the status of the monitor when the main power is turned on or the power is turned on by
remote operation.
Standby Mode Sets the status when the MAIN POWER switch is turned on.
[Off]: Operation mode
On: Standby mode
Power On Status Sets the input channel when the power is turned on.
[Last]: Sets to the channel that was selected at the time the power was last turned off.
CH: Sets to the channel number specified in Default CH.
Default CH Selects the channel (01 to 30) when the Power On Status is set to CH. [01]
On Screen Set Sets the items for the screen display.
Input Information Sets the display of the input information.
Format Sets the display mode of the signal system.
[Auto]: Disappears after being displayed for a while.
Off: Not displayed.
Note
The picture rate display is 23.98, 29.97 or 59.94 (example 1080/59.94P) when the signal is
input from the standard SDI input or the BKM-250TG, Format is set to 3G/HD/SD-SDI Auto
(page 49) in the Channel Configuration menu, and the Picture Rate information for the
Payload ID is 23.98, 29.97 or 59.94, even if the monitor determines the picture rate as 24 Hz,
30 Hz or 60 Hz.
For details on Payload ID, see “SDI Payload ID Status” (page 80) of the System Status menu
or “Displaying the Monitor Status Page” (page 98).
Position Sets the display position for the signal system.
You can select from Top Left (top left), Top Center (top center), Top Right (top right),
[Bottom Left] (bottom left), Bottom Center (bottom center) or Bottom Right (bottom right).
CH No Sets the display mode of the channel number.
[Auto]: Disappears after being displayed for a while.
Off: Not displayed.
Position Sets the display position for the channel number.
You can select from Top Left (top left), Top Center (top center), [Top Right] (top right),
Bottom Left (bottom left), Bottom Center (bottom center) or Bottom Right (bottom right).
CH Name Sets the display mode of the channel name.
[Auto]: Disappears after being displayed for a while.
Off: Not displayed.
Position Sets the display position for the channel name.
You can select from [Top Left] (top left), Top Center (top center), Top Right (top right),
Bottom Left (bottom left), Bottom Center (bottom center) or Bottom Right (bottom right).
Scan Mode Sets the display mode of the scan mode.
[Auto]: Disappears after being displayed for a while.
Off: Not displayed.
Position Sets the display position for the scan mode.
You can select from Top Left (top left), Top Center (top center), Top Right (top right),
Bottom Left
(bottom left), Bottom Center (bottom center) or [Bottom Right] (bottom right).
Closed Caption Sets the items for the closed caption display.
When the BKM-244CC is installed, you can select the item.
The setting is effective for the input signal of the BKM-244CC.
Closed Caption Sets whether or not to display closed caption signal ([Off] or On).
Type Sets the closed caption type.
[Auto1]: Select to set to 608(VBI) when the SD-SDI signal is input or 708 when the HD-
SDI signal is input.
Auto2: Select to set to 608(VBI) when the SD-SDI signal is input or 608(708) when the
HD-SDI signal is input.
708: Select to display the closed caption signal of the EIA/CEA-708 standards.
608 (708): Select to display the closed caption signal of the EIA/CEA-608 standards
transmitted by EIA/CEA-708 standards.
608 (VBI): Select to display the closed caption signal of the EIA/CEA-608 standards
transmitted by using the line 21.
Menu Function and operation ([ ]: factory setting)
