74
System Configuration Menu
Chapter 3 Menu
On Screen Set
Service 708 Sets Service when Type is set to 708.
You can select from Service1 to Service6. [Service1]
Service 608 Sets Service when Type is set to 608 (VBI) or 608 (708).
You can select from CC1 to CC4 or Text1 to Text4. [CC1]
OSD Level Sets the luminance of the letter.
You can select from High (bright), or [Low] (dark).
Audio Level Meter Sets the audio level meter.
When the BKM-250TG is installed, you can select the item.
The setting is effective for the input signal of the BKM-250TG.
Note
As the audio level meter is superimposed on the video signal, the audio level meter may be
cut partially because of the scan mode setting of the monitor.
Audio CH Sets the audio channel.
You can select from [CH1-CH8] or CH9-CH16.
Position Sets the display position of the audio level meter.
You can select from [Bottom] (bottom) or Top (top).
Transparency Sets the transparency of the background of the audio level meter.
You can select from Black (black) or [Half] (translucence).
Peak Hold Sets the peak hold mode of the audio level meter.
[Off]: The peak hold does not function.
Auto: The peak hold is automatically released after about 1 second.
Manual Reset: The peak hold is released manually.
To release the peak hold, select ALM Hold Reset (page 69) in the Function Switch menu
of the Function Setting menu or set ALM Hold Reset to on by pressing the ALM Hold
Reset button
1)
of the controller.
1)ALM Hold Reset is assigned to the controller in the Function Key menu (page 82) of the Controller
menu.
Time Code Sets the time code.
The setting is effective when the SDI signal is input.
Note
As the time code is superimposed on the video signal, the time code may be cut partially
because of the scan mode setting of the monitor.
VITC/LTC Sets the type of the time code.
You can select from [VITC] or LTC.
Position Sets the display position of the time code.
You can select from Top Left (top left), [Top Center] (top center), Top Right (top right),
Bottom Left (bottom left), Bottom Center (bottom center) or Bottom Right (bottom right).
Level Sets the luminance of the time code.
You can select High (bright) or [Low] (dark).
Over Range When a portion of the signal exceeds the dynamic range of the internal signal processing
circuit, it is determined as Over Range. This menu sets whether or not to display a zebra
pattern on the detected Over Range portion ([Off], On).
When Over Range is detected, adjust the contrast or brightness to a lower level.
Notes
• When Over Range occurs, the OVER RANGE lamp on the front of the unit lights in amber
regardless of the setting of this menu (page 17).
• When Gamut Error Display of the Function Setting menu is set to On, the zebra pattern in
the area where the error was detected is also included as a detection target of Over Range.
Password Sets the password for the menu.
Enter a four-digit number for the password. [9999]
Change Password Changes the password.
Enter New Password: Enter a new password with the numeric buttons and press the
ENTER (Ent) button.
Re-Enter Password: Enter the new password again and press the ENTER (Ent) button.
The password is registered.
To change it, press the MENU button.
Menu Function and operation ([ ]: factory setting)
