21
KV-27FA310/27FS120/29FA310/29FS120
KV-27FA310/27FS120/29FA310/29FS120
NTSC
Init
Data
VAR
1 VSIZ
V RAMP SIZE
48
VAR
2 VPOS
V POSITION ( RAMP DC )
40
VAR
3VLIN
V LINEARITY
26
VAR
4SCOR
S CORRECTION
24
VAR
5TRAP
EW TRAPESIUM
22
VAR
6 PAMP
PARABOLA ( EW PIN )
24
VAR
7UPIN
UPPER CORNER ( UPPER PIN )
31
VAR
8LPIN
LOWER CORNER ( LOWER PIN )
31
VAR
9 ABLG
ABL GAIN
15
VAR
10 SCON
SUB CONTRAST LEVEL
13
VAR
11 VPW
JUMP PULSE WIDTH
1
16 : 9
Service
Group
Item name & ( Description )Name
Fix/
Var
No.
