KV-27FA310/27FS120/29FA310/29FS120
KV-27FA310/27FS120/29FA310/29FS120
NTSC
Init Video YUV 16:09
Data
VAR
1 RDRV
R DRIVE
64
64 64 N/A
VAR 2 GDRV
G DRIVE: GDOF OFFSET ( only Color Temp. "Warm")
45 45 48 N/A
VAR 3 BDRV
B DRIVE: BDOF OFFSET ( only Color Temp. "Warm")
45 45 44 N/A
VAR
4 RCUT
HARDWARE AKB (R) CMP DATA
120
120 120 N/A
VAR 5 GCUT
HARDWARE AKB (G) CMP DATA
91 91 90 N/A
VAR 6 BCUT
HARDWARE AKB (B) CMP DATA
87 87 105 N/A
VAR
7SCON
SUB CONTRAST LEVEL
19
19 19 N/A
VAR
8 SHUE
SUB TINT (HUE)
777
N/A
VAR
9SCOL
SUB COLOR LEVEL
14 14 24
N/A
VAR
10 SBRT
SUB BRIGHTNESS
13 13 15
N/A
FIX 11 RON
R OUTPUT ON ( 0:R OUTPUT OFF 1:R OUTPUT ON )
1
FIX 12 GON
G OUTPUT ON ( 0:R OUTPUT OFF 1:R OUTPUT ON )
1
FIX 13 BON
B OUTPUT ON ( 0:R OUTPUT OFF 1:R OUTPUT ON )
1
FIX 14 BLLV
BLUE STRETCH ( 00:NO<->11:DEEP ) only Color Temp "Cool"
1
FIX
15 MTRX
MATRIX RATIO SELECT
0
FIX
16 AXIS
R-Y PHASE SELECT
52
VAR 17 SSHO
SUB SHARPNESS GAIN (OVER) RF/VIDEO
10 25 25 N/A
VAR 18 SSHP
SUB SHARPNESS GAIN (PRE) RF/VIDEO
15 30 30 N/A
VAR 19 SHPF
SHARPNESS FOR ( 00:2 CLK <-> 11:5 CLK )
100N/A
FIX 20 SHCL
SHARPNESS CORING LEVEL
0
FIX
21 SHMX
SHARPNESS LIMITER LEVEL
15
FIX
22 ACLV
ACL GAIN
0
FIX
23 AKBD
AKB SELF DIAGNOSTIC COUNTER (@1 SEC)
2
FIX
24 AKBS
AKB SWITCH ( 0:AKB OFF 1:H/W AKB ON )
1
FIX
25 REFP
AKB REFPLS TIMING
0
FIX
26 YNRC
YNR LIMITER LEVEL
15
FIX
27 BKON
BLACK STRETCH ON
1
FIX 28 BKAT
BLACK STRETCH DETECTOR TIME CONSTANT1
15
FIX 29 BKRC
BLACK STRETCH DETECTOR TIME CONSTANT2
4
FIX 30 BKDP
BLACK STRETCH DEPTH
soft cont'l
FIX
31 BKSP
BLKSTPNT BLACK STRETCH POINT
2
VP1
Service
Group
Fix/
Var
Name Item name & ( Description )No.
