28
KV-27FA310/27FS120/29FA310/29FS120
KV-27FA310/27FS120/29FA310/29FS120
NTSC
Init Video YUV 16:09
Data
FIX 31 VSSW
SYNC SLICE LVL(V)_W ( SYNC SLICE LEVEL [ V ] Wide Window
0
FIX
32 AF2S
AFC2_SEL ( ADC2 TIMING SW )
0
FIX
33 VSL2
V_SYNC_LPF_2 ( DIGITAL V_SINC_LPF [ Fall ] )
0
FIX
34 VSL1
V_SYNC_LPF_1 ( DIGITAL V_SINC_LPF [ Rise ] )
1
FIX
35 VYUV
YUV VSIZE OFFSET ( YUV V-SIZE OFFSET )
8
FIX
36 VYVP
YUV VPOS OFFSET ( YUV V-POSITION OFFSET )
8
FIX
37 VYHS
YUV HSIZE OFFSET ( YUV H-SIZE OFFSET )
8
FIX
38 VYHP
YUV HPOS OFFSET ( YUV H-POSITION OFFSET)
7
FIX
39 VSHE
V-SHRINK MODE ( V-SHRINK MODE for AV )
0
FIX
40 VYRB
YUV RBLK ( YUV RBLK OFFSET )
7
FIX
41 VYLB
YUV LBLK ( YUV LBLK OFFSET )
7
NTSC
Init Video YUV 16:09
Data
FIX 1 PCLP
pedestal CLAMP ON/OFF ( SYNC TIP/PEDESTAL CLAMP
SELECT )
0
FIX 2 VRT
VRT Voltage ( ADC REFERENCE [ 00:1.15Vpp 01:1.25 Vpp
10:1.35 Vpp 11:1.45 Vpp ] )
1
FIX
3 14HI
INV 14H CLK ( 4fsc [ Skew ] CLK POLARITY )
0
00N/A
FIX
4 14HD
14H CLK DLY ( 4fscCLK [ Skew ] CLK DELAY ADJUST )
0
00N/A
FIX
5DSI
INV DS CLK ( 8fscCLK POLARITY )
0
00N/A
FIX
6DSD
DS CLK DLY ( 8fscCLK DELAY ADJUST )
0
00N/A
FIX
7 ADCD
AD CLK DLY ( ADC CLK DELAY ADJUSTO )
0
01N/A
FIX
84FSC
4FSC SW ( AD/LOGIC CLK SWAP )
0
FIX
9WSTH
WEAK_SIG_VTH ( WEAK_SIGNAL VTH )
0
FIX
10 WSVA
WEAK SIG VIDEO ATT ( WEAK SIGNAL VIDEO ATT )
0
00N/A
FIX
11 WSCA
WEAK SIG CHROMA ATT (WEAK SIGNAL CHROMA ATT)
0
00N/A
FIX
12 VREF
VREF_SEL ( AD REFERENCE SELECT [ VZ ] )
0
NTSC
Init
Data
FIX 1
HT
HT ( HALF TONE LEVEL )
0
FIX 2
OSLR
OSD LVL R ( R OSD LEVEL )
25
FIX
3OSLG
OSD LVL G ( G OSD LEVEL )
25
FIX
4OSDC
OSD COMP ( OSD COMP )
0
FIX
5OSLB
OSD LVL B ( B OSD LEVEL )
25
DEFDOTHEROSD
Service
Group
Fix/
Var
No.
NameNo.
Service
Group
Fix/
Var
No.
Service
Group
Fix/
Var
Item name & ( Description )
Item name & ( Description )
Name
Name Item name & ( Description )
