29
KV-27FA310/27FS120/29FA310/29FS120
KV-27FA310/27FS120/29FA310/29FS120
NTSC
Init
Data
FIX
1 HRIL
H/W AKB R INI DATA L ( H/W AKB RED OUTPUT LOWER )
soft cont'l
FIX
2 HRIH
H/W AKB R INI DATA H ( H/W AKB RED OUTPUT UPPER )
soft cont'l
FIX 3 HGIL
H/W AKB G INI DATA L ( H/W AKB GREEN OUTPUT LOWER )
soft cont'l
FIX 4 HGIH
H/W AKB G INI DATA H ( H/W AKB GREEN OUTPUT UPPER )
soft cont'l
FIX
5HBIL
H/W AKB B INI DATA L (H/W AKB BLUE OUTPUT LOWER)
soft cont'l
FIX
6HBIH
H/W AKB B INI DATA H (H/W AKB BLUE OUTPUT UPPER)
soft cont'l
FIX
7HLM1
AKB_LIM1<7:0> ( H/W AKB LIM1 )
6
FIX
8HLM2
AKB_LIM2<7:0> ( H/W AKB LIM2 )
12
FIX
9HLM3
AKA_LIM3<7:0> ( H/W AKB LIM3 )
21
FIX
10 HAD1
AKB_ADD1<7:0> ( H/W AKB SPEED1 )
2
FIX
11 HAD2
AKB_ADD2<7:0> ( H/W AKB SPEED2 )
6
FIX
12 HAKE
AKB_EN ( H/W AKB MANUAL [ MCU ] / HARD
1
FIX 13 HASP
AKB_SPEED
(
H/W AKB SPEED
)
3
FIX 14 HERL
AKB_SWERR<7:0>
(
H/W AKB ERROR DET THRESH
)
40
FIX
15 HLMC
AKB_ERRC<7:0> ( H/W AKB ERROR DET TIME )
20
FIX
16 HPWL
AKBSWPON<7:0> ( H/W AKB POWER ON TRESH )
4
FIX
17 HPWC
AKB_PWERRC ( H/W AKB POWER ON TIME )
90
FIX 18 HFMT
H/W AKB2 HOLD TIMER ( H/W AKB2 HOLD TIMER (@
100 MSEC ) [ 0: No hold ]
20
FIX 19 SPMT
AKB POW ON MUTE EXIT ( AKB POWER ON MUTE EXIT
TIMMER )
120
H/W AKB
Service
Group
Fix/
Var
Item name & ( Description )No. Name
