Sony TRINITRON KV-27FA310 - Page 30

30
KV-27FA310/27FS120/29FA310/29FS120
KV-27FA310/27FS120/29FA310/29FS120
29FA310 27/29FS120
VAR
1 SBAL
SBAL ( SUB BALANCE )
44
VAR
2 SBAS
SBAS ( SUB BASS )
00
VAR
3STRE
STRE ( SUB TREBLE )
60
VAR
4SRL
SRL ( SURROUND LEVEL )
00
VAR
5 BBOL
BBOL ( SURROUND OFF-BBE LOW )
86
VAR
6 BBOH
BBOH ( SURROUND OFF-BBE HIGH)
45
VAR
7 BBSL
BBSL ( SIMULATE BBE LOW )
24
VAR
8 BBSH
BBSH ( SIMULATE BBE HIGH )
44
VAR
9 BBGL
BBGL ( WOW GAME BBE LOW )
60
VAR
10 BBGH
BBGH ( WOW GAME BBE HIGH )
40
VAR
11 BBTL
BBTL ( SRS BBE LOW )
06
VAR
12 BBTH
BBTH ( SRS BBE HIGH )
04
VAR
13 BBDL
BBDL ( Audio Processor Prologic BBE Low for DOLBY )
60
VAR
14 BBDH
BBDH ( Audio Processor Prologic BBE High for DOLBY )
40
VAR
15 VFIX
VFIX ( AUDIO OUTPUT FIX DATA )
0 243
VAR
16 AGCL
AGCL ( AGC LEVEL )
22
VAR
17 VCOF
RF OFFSET DATA
99
29FA310 27/29FS120
VAR
1 BBEL
SUB AUDIO PROCESSOR PROLOGIC BBE LOW
90
VAR
2 BBEH
SUB AUDIO PROCESSOR PROLOGIC BBE HIGH
90
VAR
3 BBOL
SURROUND OFF-BBE LOW
90
VAR
4 BBSL
SIMULATE BBE LOW
50
VAR
5 BBGL
WOW GAME BBE LOW
10 0
VAR
6AGCL
SUB AUDIO PROCESSOR AGC LEVEL
20
VAR
7 DDOF
DOLBY OFFSET DATA
15 0
NTSC
NTSC
AUDIO
PROCE
SSOR
No. Name
AP2
Service
Group
Fix/
Var
Item name & ( Description )
Service
Group
Fix/
Var
No. Name Item name & ( Description )
