Sony TRINITRON KV-27FA310 - Page 31

31
KV-27FA310/27FS120/29FA310/29FS120
KV-27FA310/27FS120/29FA310/29FS120
NTSC
Init
Data
FIX
1DISP
DISP ( OSD HORIZONTAL OFFSET ) 55
FIX
2 CCHP
CCHP ( FOR TILT DATA CALCULATION ) 80
FIX 3 HRLW
HRLW ( LOW LIMIT OF H-PULSE COUNTING WINDOW [ RF
]
16
FIX 4 HRHG
HRLG ( HIGH LIMIT OF H-PULSE COUNTING WINDOW [ RF
]
64
FIX
5HSDT
HSDTCT ( H-PULSE DETECTION [ S-VIDEO ]
8
FIX 6 STPI
STPI ( GRADUAL CONTRAST INCREASE STARTING LEVEL )
40
FIX 7 RAPI
RAPI (GRADUAL CONTRAST INCREASE Vsync COUNTER)
10
NTSC
Init
Data
VAR
ID0
Language related
81
VAR
ID1
Video related
31
VAR
ID2
Audio related
113
VAR
ID3
Miscellaneous
130
VAR
ID4
Miscellaneous
32
VAR
ID5
Miscellaneous
24
VAR
ID6
Miscellaneous
48
VAR
ID7
Miscellaneous
69
Feature
Service
Group
Fix/
Var
No.
Service
Group
Fix/
Var
No.
MICROPRO
CESSOR
Name
Item name & ( Description )Name
Item name & ( Description )
