KV-27FA310/27FS120/29FA310/29FS120
KV-27FA310/27FS120/29FA310/29FS120
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
C640 1-164-645-11 CERAMIC 1000pF 10% 500V
(KV-27FS120/29FS120LN/29FS120LS ONLY)
C642 1-126-969-11 ELECT 220µF 20% 50V
(KV-27FS120/29FS120LN/29FS120LS ONLY)
C643 1-130-777-00 MYLAR 0.1µF 5% 100V
(KV-27FS120/29FS120LN/29FS120LS ONLY)
C645 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
(KV-27FS120/29FS120LN/29FS120LS ONLY)
C647 1-126-947-11 ELECT 47µF 20% 35V
(KV-27FS120/29FS120LN/29FS120LS ONLY)
C648 1-104-330-91 CERAMIC 470pF 10% 1KV
(KV-27FS120/29FS120LN/29FS120LS ONLY)
C650 1-126-942-61 ELECT 1000µF 20% 25V
(KV-27FS120/29FS120LN/29FS120LS ONLY)
C651 1-126-942-61 ELECT 1000µF 20% 25V
(KV-27FS120/29FS120LN/29FS120LS ONLY)
C652 1-164-227-11 CERAMIC CHIP 0.022µF 10% 25V
(KV-27FS120/29FS120LN/29FS120LS ONLY)
C655 1-104-330-91 CERAMIC 470pF 10% 1KV
(KV-27FS120/29FS120LN/29FS120LS ONLY)
C660 1-126-947-11 ELECT 47µF 20% 35V
C661 1-104-665-11 ELECT 100µF 20% 25V
C665 1-104-665-11 ELECT 100µF 20% 25V
C672 1-137-756-22 FILM 22000pF 3% 800V
(KV-27FS120/29FS120LN/29FS120LS ONLY)
C673 1-126-963-11 ELECT 4.7µF 20% 50V
!
C680 1-117-699-11 CERAMIC 0.001µF 20% 250V
C690 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C901 1-218-712-11 METAL CHIP 6.8K 0.50% 1/10W
CONNECTOR
* CN002 1-564-510-11 PLUG, CONNECTOR 7P
(KV-27FS120/29FS120LN/29FS120LS ONLY)
* CN002 1-564-509-11 PLUG, CONNECTOR 6P
(KV-27FA310/29FA310 ONLY)
* CN003 1-560-124-00 PLUG, CONNECTOR (2.5MM) 4P
* CN004 1-564-510-11 PLUG, CONNECTOR 7P
* CN401 1-564-507-11 PLUG, CONNECTOR 4P
* CN404 1-564-507-11 PLUG, CONNECTOR 4P
(KV-27FA310/29FA310 ONLY)
* CN501 1-573-963-11 PIN, CONNECTOR (PC BOARD) 3P
* CN506 1-564-507-11 PLUG, CONNECTOR 4P
(KV-27FS120/29FS120LN/29FS120LS ONLY)
* CN515 1-580-798-11 CONNECTOR PIN (DY) 6P
* CN585 1-564-511-11 PLUG, CONNECTOR 8P
*
!
CN600 1-580-843-11 PIN, CONNECTOR (POWER)
* CN601 1-580-843-11 PIN, CONNECTOR (POWER)
(KV-27FA310/29FA310 ONLY)
* CN602 1-564-509-11 PLUG, CONNECTOR 6P
(KV-27FA310/29FA310 ONLY)
DIODE
D002 8-719-109-89 DIODE RD5.6ESB2
D003 8-719-110-17 DIODE RD10ESB2
D004 8-719-110-17 DIODE RD10ESB2
D005 8-719-110-17 DIODE RD10ESB2
D006 8-719-921-44 DIODE MTZJ-5.1C
D007 8-719-982-22 DIODE MTZJ-30D
D046 8-719-109-89 DIODE RD5.6ESB2
D047 8-719-109-89 DIODE RD5.6ESB2
D050 8-719-510-02 DIODE D1NS4
D051 6-500-175-01 DIODE 1E3-TB
D052 8-719-109-89 DIODE RD5.6ESB2
D200 8-719-929-15 DIODE HZS9.1NB2
D201 8-719-929-15 DIODE HZS9.1NB2
D202 8-719-929-15 DIODE HZS9.1NB2
D203 8-719-929-15 DIODE HZS9.1NB2
D204 8-719-929-15 DIODE HZS9.1NB2
D205 8-719-929-15 DIODE HZS9.1NB2
D206 8-719-070-62 DIODE PDZ9.1B-115
D207 8-719-404-50 DIODE MA111-TX
D208 8-719-929-15 DIODE HZS9.1NB2
D209 8-719-404-50 DIODE MA111-TX
D230 8-719-108-12 DIODE RD9.1EW
D231 8-719-108-12 DIODE RD9.1EW
D232 8-719-108-12 DIODE RD9.1EW
D234 8-719-108-12 DIODE RD9.1EW
D235 8-719-108-12 DIODE RD9.1EW
D236 8-719-108-12 DIODE RD9.1EW
D237 8-719-108-12 DIODE RD9.1EW
D317 8-719-108-12 DIODE RD9.1EW
D321 8-719-110-17 DIODE RD10ESB2
D351 8-719-109-66 DIODE RD3.3ESB2
D390 8-719-404-50 DIODE MA111-TX
D401 8-719-921-63 DIODE MTZJ-7.5B
D405 8-719-991-33 DIODE 1SS133T-77
