KV-27FA310/27FS120/29FA310/29FS120
KV-27FA310/27FS120/29FA310/29FS120
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
D412 1-216-864-11 SHORT CHIP
D414 8-719-921-63 DIODE MTZJ-7.5B
D430 8-719-929-15 DIODE HZS9.1NB2
D431 8-719-929-15 DIODE HZS9.1NB2
D500 8-719-404-50 DIODE MA111-TX
D501 8-719-404-50 DIODE MA111-TX
D505 8-719-081-00 DIODE BY228/A52A/
D506 8-719-312-10 DIODE RU4AM-T3
D507 8-719-991-33 DIODE 1SS133T-77
D508 8-719-404-50 DIODE MA111-TX
D510 8-719-081-00 DIODE BY228/A52A/
D513 8-719-404-50 DIODE MA111-TX
D514 8-719-908-03 DIODE GP08D
D515 8-719-908-03 DIODE GP08D
D525 8-719-991-33 DIODE 1SS133T-77
D526 8-719-074-25 DIODE PG104R
D528 8-719-991-33 DIODE 1SS133T-77
D545 8-719-908-03 DIODE GP08D
D558 8-719-404-50 DIODE MA111-TX
D559 8-719-404-50 DIODE MA111-TX
D562 8-719-991-33 DIODE 1SS133T-77
! D566 8-719-979-84 DIODE EGP20DPKG23
! D567 8-719-991-33 DIODE 1SS133T-77
! D568 8-719-921-63 DIODE MTZJ-7.5B
D569 8-719-921-44 DIODE MTZJ-5.1C
D587 8-719-074-25 DIODE PG104R
D589 8-719-991-33 DIODE 1SS133T-77
D596 8-719-979-85 DIODE EGP20G
D598 8-719-979-85 DIODE EGP20G
D603 8-719-064-12 DIODE S1NB60-4062
D604 6-500-890-01 DIODE 1N5406G-EB
(KV-27FS120/29FA310LN/29FS120LN ONLY)
D605 8-719-510-53 DIODE D4SB60L
(KV-29FS120LS/29FA310LS ONLY)
D606 6-500-890-01 DIODE 1N5406G-EB
(KV-27FS120/29FA310LN/29FS120LN ONLY)
D611 8-719-510-73 DIODE S3L20UF4
(KV-27FS120/29FS120LS/29FS120LN ONLY)
D612 8-719-068-00 DIODE ERC04-06SE
(KV-27FS120/29FA310LN/29FS120LN ONLY)
D613 8-719-068-00 DIODE ERC04-06SE
(KV-27FS120/29FA310LN/29FS120LN ONLY)
D614 8-719-057-52 DIODE EZ0150AV1
(KV-27FS120/29FS120LN/29FS120LS ONLY)
D615 6-500-177-01 DIODE MA7D50
(KV-27FS120/29FS120LN/29FS120LS ONLY)
D618 8-719-979-64 DIODE UF4005PKG23
(KV-27FS120/29FS120LN/29FS120LS ONLY)
D620 8-719-911-19 DIODE 1SS119-25
D621 8-719-510-37 DIODE D5LC20U
(KV-27FS120/29FS120LN/29FS120LS ONLY)
D624 8-719-510-73 DIODE S3L20UF4
(KV-27FS120/29FS120LN/29FS120LS ONLY)
D628 8-719-404-50 DIODE MA111-TX
D629 8-719-110-31 DIODE RD12ESB2
D631 6-500-175-01 DIODE 1E3-TB
(KV-27FS120/29FS120LN/29FS120LS ONLY)
D641 8-719-991-33 DIODE 1SS133T-77
D642 8-719-982-22 DIODE MTZJ-30D
D644 8-719-110-31 DIODE RD12ESB2
D645 8-719-109-89 DIODE RD5.6ESB2
D650 8-719-109-89 DIODE RD5.6ESB2
FUSE
! F601 1-532-506-51 FUSE 6.3A 250V
(KV-29FS120LS/29FA310LS ONLY)
! F601 1-576-193-11 FUSE 6.3A 125V
(KV-27FS120/29FA310LN/29FS120LN ONLY)
FERRITE BEAD
FB301 1-410-397-21 FERRITE 1.1µH
FB505 1-410-397-21 FERRITE 1.1µH
FB506 1-410-397-21 FERRITE 1.1µH
FB522 1-410-397-21 FERRITE 1.1µH
FB601 1-410-397-21 FERRITE 1.1µH
(KV-27FS120/29FS120LN/29FS120LS ONLY)
FB602 1-410-397-21 FERRITE 1.1µH
(KV-27FS120/29FS120LN/29FS120LS ONLY)
FB603 1-410-397-21 FERRITE 1.1µH
(KV-27FS120/29FS120LN/29FS120LS ONLY)
FB604 1-410-397-21 FERRITE 1.1µH
(KV-27FS120/29FS120LN/29FS120LS ONLY)
FB605 1-410-397-21 FERRITE 1.1µH
FB616 1-469-578-11 FERRITE 1.1µH
(KV-27FS120/29FS120LN/29FS120LS ONLY)
