64
KV-27FA310/27FS120/29FA310/29FS120
KV-27FA310/27FS120/29FA310/29FS120
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
FB617 1-469-578-11 FERRITE 1.1µH
(KV-27FS120/29FS120LN/29FS120LS ONLY)
FILTER
FL001 1-239-803-11 ENCAPSULATED COMPONENT
IC
IC001 6-804-178-01 IC M65582AUF-XXXFP
IC002 6-704-004-01 IC BR24L16F-WE2
IC003 8-759-352-91 IC PST9143NL
IC321 8-759-353-00 IC NJM2534M(TE2)
IC400 6-703-190-01 IC NJW1134AGK1-TE2
(KV-27FS120/29FS120LN/29FS120LS ONLY)
IC400 6-706-033-01 IC W1172JK1-TE
(KV-27FA310/29FA310 ONLY)
IC404 6-705-054-01 IC TDA8947J
IC545 8-759-696-71 IC STV9379A
IC561 8-759-700-07 IC NJM2903M
IC565 8-759-700-44 IC NJM2902M
IC600 6-705-810-01 IC MCZ3001DB
(KV-27FS120/29FS120LN/29FS120LS ONLY)
IC603 6-705-818-01 IC MC7809CF
(KV-27FS120/29FS120LN/29FS120LS ONLY)
IC603 6-705-466-01 IC BA90BC0T
(KV-27FA310/29FA310 ONLY)
IC604 8-749-012-13 IC DM-58
(KV-27FS120/29FS120LN/29FS120LS ONLY)
IC608 8-759-450-47 IC BA05T
IC633 6-703-080-01 IC LF33CV
JACK
J200 1-794-119-11 TERMINAL BLOCK, S 4P
J202 1-794-118-11 JACK BLOCK, PIN 3P
* J203 1-817-461-11 PIN JACK BLOCK 5P
J205 1-794-116-11 JACK BLOCK, PIN 2P
(KV-27FS120/29FS120LN/29FS120LS ONLY)
J205 1-818-352-11 PIN JACK W/ DIN CONNECTOR
(KV-27FA310/29FA310 ONLY)
CHIP CONDUCTOR
JR2 1-216-864-11 SHORT CHIP
JR6 1-216-864-11 SHORT CHIP
JR7 1-216-864-11 SHORT CHIP
JR12 1-216-864-11 SHORT CHIP
JR44 1-216-864-11 SHORT CHIP
JR102 1-216-864-11 SHORT CHIP
JR128 1-216-864-11 SHORT CHIP
JR201 1-216-864-11 SHORT CHIP
JR207 1-216-864-11 SHORT CHIP
JR209 1-216-864-11 SHORT CHIP
JR211 1-216-864-11 SHORT CHIP
JR212 1-216-864-11 SHORT CHIP
JR213 1-216-864-11 SHORT CHIP
JR214 1-216-864-11 SHORT CHIP
JR215 1-216-864-11 SHORT CHIP
JR216 1-216-864-11 SHORT CHIP
(KV-27FS120/29FS120LN/29FS120LS ONLY)
JR255 1-216-864-11 SHORT CHIP
JR301 1-216-864-11 SHORT CHIP
JR302 1-216-864-11 SHORT CHIP
JR303 1-216-864-11 SHORT CHIP
JR304 1-216-864-11 SHORT CHIP
JR305 1-216-864-11 SHORT CHIP
JR306 1-216-864-11 SHORT CHIP
JR310 1-216-864-11 SHORT CHIP
JR311 1-216-864-11 SHORT CHIP
JR312 1-216-864-11 SHORT CHIP
JR315 1-216-864-11 SHORT CHIP
JR317 1-216-864-11 SHORT CHIP
JR401 1-216-864-11 SHORT CHIP
JR411 1-216-864-11 SHORT CHIP
JR485 1-216-864-11 SHORT CHIP
JR486 1-216-864-11 SHORT CHIP
JR504 1-216-864-11 SHORT CHIP
JR585 1-216-864-11 SHORT CHIP
JR586 1-216-864-11 SHORT CHIP
JR1502 1-216-864-11 SHORT CHIP
JUMPER WIRE
JW57 1-249-409-11 CARBON 220 5% 1/4W
