Sony TRINITRON KV-27FA310 - Page 65

65
KV-27FA310/27FS120/29FA310/29FS120
KV-27FA310/27FS120/29FA310/29FS120
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
COIL
L002 1-239-803-11 ENCAPSULATED COMPONENT
L003 1-239-803-11 ENCAPSULATED COMPONENT
L004 1-239-803-11 ENCAPSULATED COMPONENT
L005 1-239-803-11 ENCAPSULATED COMPONENT
L006 1-414-273-11 INDUCTOR 100µH
L007 1-414-273-11 INDUCTOR 100µH
L008 1-414-857-11 INDUCTOR 100µH
L009 1-414-857-11 INDUCTOR 100µH
L010 1-414-267-21 INDUCTOR 10µH
L011 1-239-803-11 ENCAPSULATED COMPONENT
L101 1-414-229-11 FERRITE 0µH
L513 1-406-677-11 INDUCTOR 10MH
L515 1-412-552-11 INDUCTOR 2.2MH
L516 1-419-714-11 INDUCTOR 100µH
L525 1-409-955-31 INDUCTOR 8MH
L527 1-410-397-21 FERRITE 1.1µH
! L588 1-412-523-41 INDUCTOR 6.8µH
L606 1-412-525-31 INDUCTOR 10µH
(KV-27FS120/29FS120LN/29FS120LS ONLY)
L607 1-412-525-31 INDUCTOR 10µH
(KV-27FS120/29FS120LN/29FS120LS ONLY)
L608 1-412-533-21 INDUCTOR 47µH
(KV-27FS120/29FS120LN/29FS120LS ONLY)
L608 1-410-397-21 INDUCTOR 1.1µH
(KV-27FA310/29FA310 ONLY)
L609 1-412-525-31 INDUCTOR 10µH
PHOTO COUPLER
! PH602 8-749-010-64 PHOTO COUPLER PC123F2
(KV-27FS120/29FS120LN/29FS120LS ONLY)
IC LINK
PS401 1-576-337-21 IC LINK 2.7A 50V
TRANSISTOR
Q002 8-729-422-27 TRANSISTOR 2SD601A-Q
Q004 8-729-422-27 TRANSISTOR 2SD601A-Q
Q005 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q006 8-729-422-27 TRANSISTOR 2SD601A-Q
Q008 8-729-422-27 TRANSISTOR 2SD601A-Q
Q009 8-729-422-27 TRANSISTOR 2SD601A-Q
Q300 8-729-422-27 TRANSISTOR 2SD601A-Q
Q301 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q303 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q304 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q305 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q306 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q316 8-729-422-27 TRANSISTOR 2SD601A-Q
Q390 8-729-422-27 TRANSISTOR 2SD601A-Q
Q391 8-729-422-27 TRANSISTOR 2SD601A-Q
Q400 8-729-422-27 TRANSISTOR 2SD601A-Q
Q401 8-729-422-27 TRANSISTOR 2SD601A-Q
Q404 8-729-422-27 TRANSISTOR 2SD601A-Q
Q411 8-729-422-27 TRANSISTOR 2SD601A-Q
Q412 8-729-422-27 TRANSISTOR 2SD601A-Q
Q501 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
Q502 8-729-140-50 TRANSISTOR 2SC3209LK
Q503 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q504 8-729-422-27 TRANSISTOR 2SD601A-Q
Q505 6-550-107-01 TRANSISTOR 2SD2645-YB
Q521 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
Q522 8-729-053-87 TRANSISTOR KTC4370A
Q531 8-729-422-27 TRANSISTOR 2SD601A-Q
Q533 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q572 8-729-422-27 TRANSISTOR 2SD601A-Q
Q573 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q578 8-729-422-27 TRANSISTOR 2SD601A-Q
Q590 6-550-362-01 TRANSISTOR KTA1279
Q600 8-729-053-36 TRANSISTOR 2SK2640-01MR-F122
(KV-27FS120/29FS120LN/29FS120LS ONLY)
Q601 8-729-053-36 TRANSISTOR 2SK2640-01MR-F122
(KV-27FS120/29FS120LN/29FS120LS ONLY)
Q604 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q608 8-729-922-37 TRANSISTOR 2SD2144S-UVW
Q650 6-550-409-01 TRANSISTOR KSC2383-O
RESISTOR
R002 1-216-864-11 SHORT CHIP
R003 1-216-821-11 METAL CHIP 1K 5% 1/10W
R004 1-216-817-11 METAL CHIP 470 5% 1/10W
R005 1-400-427-21 FERRITE 0µH
R006 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
A
