73
KV-27FA310/27FS120/29FA310/29FS120
KV-27FA310/27FS120/29FA310/29FS120
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
COIL
L1805 1-406-677-11 INDUCTOR 10MH
TRANSISTOR
Q1810 8-729-043-95 TRANSISTOR 2SC3840(3)
RESISTOR
R1845 1-249-441-11 CARBON 100K 5% 1/4W
R1846 1-249-441-11 CARBON 100K 5% 1/4W
R1847 1-249-441-11 CARBON 100K 5% 1/4W
R1848 1-215-894-11 METAL OXIDE 2.2K 5% 2W
R1849 1-215-923-00 METAL OXIDE 10K 5% 3W
R1850 1-215-923-00 METAL OXIDE 10K 5% 3W
R1851 1-215-922-11 METAL OXIDE 6.8K 5% 3W
R1852 1-215-922-11 METAL OXIDE 6.8K 5% 3W
TRANSFORMER
T1801 1-433-533-12 TRANSFORMER, FERRITE (DFT)
GD
* A-1410-927-A GD (COM) BOARD, MOUNTED
(KV-27FA310/29FA310 ONLY)
!
1-900-807-96 WIRE ASSY, G2 LEAD 180
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C1602 1-137-150-11 FILM 0.01µF 5% 100V
C1604 1-164-625-11 CERAMIC 680pF 10% 500V
C1609 1-164-625-11 CERAMIC 680pF 10% 500V
C1616 1-126-943-11 ELECT 2200µF 20% 25V
C1617 1-123-024-21 ELECT 33µF 160V
C1620 1-137-150-11 FILM 0.01µF 5% 100V
C1624 1-107-636-11 ELECT 10µF 20% 160V
C1633 1-136-479-11 FILM 0.001µF 5% 100V
C1634 1-126-964-11 ELECT 10µF 20% 50V
C1635 1-126-963-11 ELECT 4.7µF 20% 50V
C1637 1-136-165-00 FILM 0.1µF 5% 50V
C1642 1-126-969-11 ELECT 220µF 20% 50V
C1643 1-136-165-00 FILM 0.1µF 5% 50V
C1645 1-136-479-11 FILM 0.001µF 5% 100V
C1647 1-126-947-11 ELECT 47µF 20% 35V
C1648 1-164-143-11 CERAMIC 0.001µF 10% 1KV
C1649 1-164-143-11 CERAMIC 0.001µF 10% 1KV
C1650 1-100-120-51 ELECT 1000µF 20% 35V
C1652 1-137-374-11 MYLAR 0.047µF 5% 50V
C1669 1-164-625-11 CERAMIC 680pF 10% 500V
C1670 1-164-625-11 CERAMIC 680pF 10% 500V
C1672 1-165-953-11 FILM 47000pF 3% 800V
C1680 1-117-228-71 MYLAR 2.2µF 10% 450V
C1815 1-129-718-00 FILM 0.022µF 5% 630V
C1816 1-102-244-00 CERAMIC 220pF 10% 500V
C1817 1-129-709-91 FILM 0.0039µF 5% 630V
C1818 1-164-645-11 CERAMIC 1000pF 10% 500V
C1819 1-102-244-00 CERAMIC 220pF 10% 500V
C1820 1-109-954-11 ELECT 0.47µF 20% 160V
CONNECTOR
* CN1600 1-580-843-11 PIN, CONNECTOR (POWER)
DIODE
D1611 8-719-062-40 DIODE D4SBL20µF3
D1614 8-719-057-52 DIODE EZ0150AV1
D1615 8-719-062-40 DIODE D4SBL20µF3
D1618 8-719-979-64 DIODE µF4005PKG23
D1621 6-500-181-01 DIODE MA6D50
D1631 6-500-175-01 DIODE 1E3-TB
D1809 8-719-110-41 DIODE RD15ESB2
D1810 8-719-970-87 DIODE ERA38-06
D1811 8-719-970-87 DIODE ERA38-06
D1812 8-719-081-93 DIODE 1N4937/23
FERRITE BEAD
FB1602 1-410-397-21 FERRITE 1.1µH
FB1604 1-410-397-21 FERRITE 1.1µH
FB1609 1-410-397-21 FERRITE 1.1µH
FB1616 1-410-397-21 FERRITE 1.1µH
FB1617 1-410-397-21 FERRITE 1.1µH
D
GD
