Sony TRINITRON KV-27FA310 - Page 74

74
KV-27FA310/27FS120/29FA310/29FS120
KV-27FA310/27FS120/29FA310/29FS120
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
IC
IC1600 6-705-810-01 IC MCZ3001DB
IC1601 8-749-012-13 IC DM-58
COIL
L1600 1-406-977-21 INDUCTOR 100µH
L1604 1-412-525-31 INDUCTOR 10µH
L1608 1-412-529-81 INDUCTOR 22µH
L1805 1-406-677-11 INDUCTOR 10MH
PHOTO COUPLER
PH1602 8-749-924-35 PHOTO COUPLER ON3171-R
IC LINK
PS1401 1-576-337-21 IC LINK 2.7A 50V
TRANSISTOR
Q1600 8-729-052-32 TRANSISTOR IRFIB7N50A-LF31
Q1601 8-729-052-32 TRANSISTOR IRFIB7N50A-LF31
Q1810 8-729-043-95 TRANSISTOR 2SC3840(3)
RESISTOR
! R1615 1-202-933-61 FUSIBLE 0.1 10% 1/2W
R1616 1-249-418-11 CARBON 1.2K 5% 1/4W
R1617 1-249-417-11 CARBON 1K 5% 1/4W
R1619 1-249-377-11 CARBON 0.47 5% 1/4W
R1620 1-215-857-71 METAL OXIDE 10 5% 1W
R1625 1-249-413-11 CARBON 470 5% 1/4W
R1626 1-215-443-00 METAL 8.2K 1% 1/4W
R1629 1-245-478-21 METAL 470K 1% 1/4W
R1630 1-245-478-21 METAL 470K 1% 1/4W
R1631 1-215-449-00 METAL 15K 1% 1/4W
R1632 1-215-397-00 METAL 100 1% 1/4W
R1640 1-249-417-11 CARBON 1K 5% 1/4W
R1647 1-215-396-00 METAL 91 1% 1/4W
R1650 1-249-441-11 CARBON 100K 5% 1/4W
R1651 1-249-441-11 CARBON 100K 5% 1/4W
R1658 1-249-393-11 CARBON 10 5% 1/4W
R1659 1-249-393-11 CARBON 10 5% 1/4W
R1660 1-249-429-11 CARBON 10K 5% 1/4W
R1667 1-249-429-11 CARBON 10K 5% 1/4W
R1668 1-249-418-11 CARBON 1.2K 5% 1/4W
R1670 1-249-429-11 CARBON 10K 5% 1/4W
R1671 1-243-979-71 METAL OXIDE 0.1 5% 2W
R1672 1-243-979-71 METAL OXIDE 0.1 5% 2W
R1845 1-249-441-11 CARBON 100K 5% 1/4W
R1846 1-249-441-11 CARBON 100K 5% 1/4W
R1847 1-249-441-11 CARBON 100K 5% 1/4W
R1848 1-215-894-11 METAL OXIDE 2.2K 5% 2W
R1849 1-215-923-00 METAL OXIDE 10K 5% 3W
R1850 1-215-923-00 METAL OXIDE 10K 5% 3W
R1851 1-215-922-11 METAL OXIDE 6.8K 5% 3W
R1852 1-215-922-11 METAL OXIDE 6.8K 5% 3W
TRANSFORMER
! T1604 1-437-606-12 COVERTER TRANSFORMER
T1801 1-433-533-12 TRANSFORMER, FERRITE (DFT)
HR
* A-1415-629-A HR (VAR) BOARD, MOUNTED
(KV-27FA310/29FA310 ONLY)
CAPACITOR
C3001 1-104-665-11 ELECT 100µF 20% 25V
CONNECTOR
* CN3001 1-564-521-11 PLUG, CONNECTOR 6P
DIODE
D3001 8-719-109-89 DIODE RD5.6ESB2
D3002 8-719-057-09 DIODE LNJ801LPDJA
IC
IC3001 8-742-211-20 HYB IC SBX3071-71
GD
HR
