SIZE H
Adjusts the horizontal size of the picture input from
the INPUT A/B connector.
The higher the setting, the larger the horizontal size of
the picture.
The lower the setting, the smaller the horizontal size
of the picture. Adjust the setting according to the dots
of the input signal.
For details on a suitable value for preset signals, see page
31 (GB).
SHIFT
Adjusts the position of the picture input from the
INPUT A/B connectors or video input connectors.
H adjusts the horizontal position of the picture.
V adjusts the vertical position of the picture.
As the setting for H increases, the picture moves to
the right, and as the setting decreases, the picture
moves to the left.
As the setting for V increases, the picture moves up,
and as the setting decreases, the picture moves down.
Use the < or , key to adjust the horizontal position
and the M or m key for the vertical position.
ASPECT
Sets the aspect ratio of the picture.
When inputting a 16:9 (squeezed) signal from
equipment such as a DVD player, set this to 16:9.
4:3 : When a picture with a ratio of 4:3 is input.
16:9 : When a picture with a ratio of 16:9 (squeezed)
is input.
SCAN CONV (Scan converter)
Converts the signal to display the picture according to
the screen size.
ON: Displays the picture according to the screen
size. The picture will lose some clarity.
OFF: Displays the picture while matching one pixel
of the input picture element to that of the LCD.
The picture will be clear but the picture size will
be smaller.
Note
This item will not be displayed in the following cases.
VPL-PX15/PX10: When an XGA or SXGA signal is
input.
VPL-PS10: When an SVGA, XGA or SXGA signal is
input.
Input signals and adjustable/setting items
Item Input signal
Video or Video GBR RGB
1)
S video (Y/C)
Component
DOT –––
PHASE
SIZE H –––
SHIFT
ASPECT
–
SCAN –––
2)
CONV
: Adjustable/can be set
– : Not adjustable/can not be set
1) The RGB signals of a computer
2) VPL-PX15/PX10: lower than SVGA only; VPL-PS10:
lower than VGA only
About the preset memory No.
This projector has 37 kinds of preset data for input
signals (the preset memory). The memory number of
the current input signal and the signal type are
displayed when the preset signal is input. This
projector automatically detects the signal type. When
the signal has been registered in the preset memory, a
suitable picture is displayed on the screen according to
the signal type. You can adjust the picture through the
INPUT SETTING menu.
This projector also has 20 kinds of user memories for
each INPUT A/B. When an unpreset signal is input
for the first time, the memory number is displayed as
0. If the input signal is adjusted in the INPUT
SETTING menu, the setting made via INPUT A/B is
stored. When more than 20 user memory items are
registered for each INPUT A/B, the newest memory
item is automatically stored over the oldest one.
The INPUT SETTING Menu
31
(GB)
Preset signals
1) VESA is a registered trademark of the Video Electronics
Standards Association.
2) PC-98 is a registered trademark of NEC Corporation.
3) VPL-PX15/PX10: 1296; VPL-PS10: 1012.
Since the data is recalled from the preset memory for
the following signals, you can use this preset data by
adjusting SIZE H. Make finer adjustments using
SHIFT.
Signal Memory No. SIZE H
Super Mac-2 23 1312
SGI-1 23 1320
Macintosh 19
”
25 1328
Macintosh 21
”
27 1456
Sony News 36 1708
PC-9821 36 1600
1280 × 1024
WS Sunmicro 37 1664
Note
When the aspect ratio of an input signal is other than
4:3, a part of the screen is displayed in black.
The SET SETTING Menu
The SET SETTING menu is used for changing the
settings of the projector.
Operation
1. Select an item
Use the M or m key to select the item, then press the
, or ENTER key.
2. Change the setting
Press the M or m key to change the setting.
To restore the original screen, press the ENTER or
<
key.
The INPUT SETTING Menu / The SET SETTING Menu
Memory Preset signal
fH fV Sync
SIZE
No.
(kHz) (Hz)
H
1 Video 60 Hz
15.734 59.940 H-neg V-neg
2 Video 50 Hz
15.625 50.000 H-neg V-neg
3 480/60i
15.734 59.940
S on G/Y or
4 575/50i
15.625 50.000
Composite sync
6
640 × 350
VGA mode 1
31.469 70.086 H-pos V-neg 800
7
VGA VESA
1)
85 Hz
37.861 85.080 H-pos V-neg 832
8
640 × 400
PC-9801
2)
Normal
24.823 56.416 H-neg V-neg 848
9
VGA mode 2
31.469 70.086 H-neg V-pos 800
10
VGA VESA 85 Hz
37.861 85.080 H-neg V-pos 832
11
640 × 480
VGA mode 3
31.469 59.940 H-neg V-neg 800
12
Macintosh 13
”
35.000 66.667 H-neg V-neg 864
13
VGA VESA 72 Hz
37.861 72.809 H-neg V-neg 832
14
VGA VESA 75 Hz
37.500 75.000 H-neg V-neg 840
15
VGA VESA 85 Hz
43.269 85.008 H-neg V-neg 832
16
800 × 600
SVGA VESA 56 Hz
35.156 56.250 H-pos V-pos 1024
17
SVGA VESA 60 Hz
37.879 60.317 H-pos V-pos 1056
18
SVGA VESA 72 Hz
48.077 72.188 H-pos V-pos 1040
19
SVGA VESA 75 Hz
46.875 75.000 H-pos V-pos 1056
20
SVGA VESA 85 Hz
53.674 85.061 H-pos V-pos 1048
21
832 × 624
Macintosh 16
”
49.724 74.550 H-neg V-neg 1152
22
1024 × 768
XGA VESA 43 Hz
35.524 43.479 H-pos V-pos 1264
23
XGA VESA 60 Hz
48.363 60.004 H-neg V-neg 1344
24
XGA VESA 70 Hz
56.476 69.955 H-neg V-neg 1328
25
XGA VESA 75 Hz
60.023 75.029 H-pos V-pos 1312
26
XGA VESA 85 Hz
68.677 84.997 H-pos V-pos 1376
27
1152
× 864 SXGA VESA 70 Hz
63.995 70.016 H-pos V-pos 1472
28
SXGA VESA 75 Hz
67.500 75.000 H-pos V-pos 1600
29
SXGA VESA 85 Hz
77.487 85.057 H-pos V-pos 1568
30
1152 × 900
Sunmicro LO 61.795 65.960 H-neg V-neg 1504
31
Sunmicro HI 71.713 76.047
Composite sync
1472
32
1280 × 960 SXGA VESA 60 Hz
60.000 60.000 H-pos V-pos 1800
33
SXGA VESA 75 Hz
75.000 75.000 H-pos V-pos 1728
34
1280 × 1024 SXGA VESA 43 Hz
46.433 43.436 H-pos V-pos 1696
35
SGI-5
53.316 50.062 S on G 1680
36
SXGA VESA 60 Hz
63.974 60.013 H-pos V-pos 1696
37
SXGA VESA 75 Hz
79.976 75.025 H-pos V-pos 1688
38
SXGA VESA 85 Hz
91.146 85.024 H-pos V-pos
3)
