2-2. Disassembly
2-2-1. Hood Assembly and Front Assembly Removal
Screw
(B3
x
5)
Screw
(B3
x
5)
Screw
(B3 x 5)
Two screws
(PSW3
x
90)
Screw
(PSW3
x
90)
Hood assembly
Front assembly
Lens cap (main)
1
2
3
4
5
6
7
Screw
(B3 x 5)
Matching connector
Matching
connector
8
9
H board
CN10
