Sony VPL-PS10 - Power Block Removal

2-6
VPL-PS10/PX10/PX15
2-2-6. Power Block Removal
G board
Three screws
Screw
(B3 x 5)
Two screws
(B3 x 5)
Two screws
(B3 x 5)
Two screws
(B3 x 5)
CN1101
CN1102
CN1107
1
2
3
4
5
Power block assembly
Bracket (BB)
Ballast connector
CN1108
CN1104
Sheet (G)
Sheet (BS)
Bracket (G)
Power block
6
7
8
9
!/
!-
a
a
(B3 x 5)
(B3 x 8)
(B3 x 5)
