SoundCraft Si Series User Manual

Page 4 - 15Soundcraft® Si Series User Guide
Both Rows mode
BUS SENDS button selected
The CHANNEL SCROLL buttons allow the user to navigate away from the currently-selected input fader chan-
nel to place another channel onto the encoders in both the Upper and Lower rows.
The SEL buttons in the associated input fader bay will illuminate and will track the selection made using the
CHANNEL SCROLL buttons.
NOTE: The range of the Left/Right scroll buttons are the 16 (24 on Si2) channels in the currently selected
fader bay.
OUTPUT PROCESSING button selected
The CHANNEL SCROLL buttons allow the user to navigate away from the currently-selected output channel
to place another channel onto the encoders in both the Upper and Lower rows.
The SEL buttons in the associated output fader bay will illuminate and will track the selection made using
the CHANNEL SCROLL buttons.
NOTE: The range of the Left/Right scroll buttons are the 12 master faders currently selected in the centre
section.
BUS TO MATRIX button selected
The CHANNEL SCROLL buttons allow the user to navigate away from the currently-selected matrix output in
order to place another matrix output onto the encoders in both the Upper and Lower rows.
If the MTX/MAST button is selected, the SEL buttons in the associated output fader bay will illuminate and
will track the selection made using the CHANNEL SCROLL buttons.
Note! When in Both Rows mode, the CHANNEL SCROLL buttons next to the upper and lower row of
encoders are linked in their operation.

SoundCraft Si Series Specifications

General

Model Variants	Si Expression, Si Performer, Si Compact, Si Impact
Built-in Effects	Lexicon effects engine
Type	Digital mixer
EQ Bands	4-band EQ per channel
Subgroups	4 subgroups
Effects Engines	Lexicon effects engine
Faders	Motorized faders
Display	Varies by model
Dimensions	Varies by model
Weight	Varies by model
