SoundCraft Ui16 User Manual

CONTENTS
CONTENTS
CONTENTS
1.0 AN INTRODUCTION TO Ui
1.1: Safety
1.2: Warranty
 1.3:Specications
2.0: GETTING STARTED
2.1: System Overview
2.2: Hardware I/O & Control
2.3: Input Channel Routing
2.4: Getting Connected
3.0: SOFTWARE CONTROL
3.0.1: Updates & Requirements
3.0.2: Reset The Mixer
3.1: Software Navigation
3.1.1: Control / Gesture Summary
3.2: Tablet Navigation
3.2.1: Keyboard Control
3.3: Tablet Screens
3.4: Phone Navigation
3.5: Phone Screens
4.0: MIXER CHANNELS
4.1: Input Gain Page
4.2: Input Mix Page
4.2.1: Input Sub Menu
4.3: Aux Sends
4.3.1: Aux Master
4.4: FX Sends
4.5: Group Master
4.6: Master Channel
4.6.1: Master Channel Sub-Menu
5.0: CHANNEL EDIT
5.1: DigiTech
5.2: Parametric EQ
5.3: Graphic EQ
5.3.1 AFS
2
- Feedback Elimination
5.4: Dynamics
5.5: Aux / FX Sends
6.0: MIX FEATURES
6.1: View & Mute Groups
6.2: MOREME
7.0: LEXICON FX EDIT
7.1: Reverb
7.2: Delay
7.3: Chorus
8.0: SHOWS & SNAPSHOTS
9.0: MEDIA PLAYER & RECORDER
10.0: SETTINGS
 10.1:NetworkConguration
10.1.1: Hotspot Settings
10.1.2: Wi-Fi Settings
10.1.3: LAN Settings
APPENDIX 01: Troubleshooting: No Sound?
APPENDIX 02: Troubleshooting: System FAQ
APPENDIX 03: F/W Update
For clarity, this manual uses section references rather than page numbers. In some instances, one section reference
may extend to several pages.
Ui12, Ui16 User Manual

SoundCraft Ui16 Specifications

General

Channels	16
Mic Preamps	8
USB Playback	Yes
Built-in Wi-Fi	Yes
XLR Inputs	8
Aux Sends	4
Phantom Power	Yes
Sampling Rate	48 kHz
Bit Depth	24-bit
Ethernet Port	1
Remote Control	Remote control via HTML5-compatible browser
RCA Inputs	2
Control	Control via any device with a web browser
Wi-Fi	Built-in Wi-Fi
Microphone Preamps	8
USB Audio Interface	2-channel recording/playback
Monitor Outputs	2
Aux Outputs	4
Power Supply	Internal
USB	USB playback and recording
Dimensions	177 x 482 x 89 mm
Weight	3.9kg (8.6 lbs)
