SoundCraft Ui16 User Manual

4.6.1: MASTER SUB-MENU
CHANNELS > MASTER CHANNEL > SUB MENU
4.6.1: MASTER CHANNEL SUB-MENU
Ui12, Ui16 User Manual
SET TO ZERO DB
This is a fast way to set the channel fader level back to zero dB. Double tap the MASTER channel name, then
touch SET TO ZERO DB.
MASTER PRESETS
SaveMasterChannelsetupsaspresets.Usefulforbuildingupalibraryofnal-stageprocessingset-ups.
By long-clicking/tapping on a the Master Channel name you can access the Master Channel sub-menu for
access to the ‘Set To Zero’ function and the Master Channel Preset Manager.

SoundCraft Ui16 Specifications

General

Channels	16
Mic Preamps	8
USB Playback	Yes
Built-in Wi-Fi	Yes
XLR Inputs	8
Aux Sends	4
Phantom Power	Yes
Sampling Rate	48 kHz
Bit Depth	24-bit
Ethernet Port	1
Remote Control	Remote control via HTML5-compatible browser
RCA Inputs	2
Control	Control via any device with a web browser
Wi-Fi	Built-in Wi-Fi
Microphone Preamps	8
USB Audio Interface	2-channel recording/playback
Monitor Outputs	2
Aux Outputs	4
Power Supply	Internal
USB	USB playback and recording
Dimensions	177 x 482 x 89 mm
Weight	3.9kg (8.6 lbs)
