SoundCraft Ui16 User Manual

Ui12, Ui16 User Manual
5.1: DIGITECH
CHANNEL EDIT > DIGITECH
5.1: DIGITECH
DigiTechinputprocessingandchannelviewisavailabletothersttwoUimixerchannels,and
includes Hi-Z (high input impedance) selection for sources such direct-input guitar pick-ups.
The DigiTech processing includes amp modelling: Emulations of guitar amps (with associated param-
eters) and cabinets. The DigiTech view also allows single-view editing of selected channel features via
the ‘Jack-Plug Buttons’.
AMP SELECT
Choose a guitar amp model
Clicking or tapping anywhere on the guitar amp graphic will bring up a pop-up menu of available guitar amp
models.
CAB SELECT
Choose a guitar speaker cabinet model
Clicking or tapping anywhere on the guitar cab graphic will bring up a pop-up menu of available guitar cab
models.
HI-Z ON/OFF
Turn the Hi-Z input on or off
If you have an input source that requires a high impedance input - such as the direct output from electric guitar
pick-ups - turn the Hi-Z option on.

SoundCraft Ui16 Specifications

General

Channels	16
Mic Preamps	8
USB Playback	Yes
Built-in Wi-Fi	Yes
XLR Inputs	8
Aux Sends	4
Phantom Power	Yes
Sampling Rate	48 kHz
Bit Depth	24-bit
Ethernet Port	1
Remote Control	Remote control via HTML5-compatible browser
RCA Inputs	2
Control	Control via any device with a web browser
Wi-Fi	Built-in Wi-Fi
Microphone Preamps	8
USB Audio Interface	2-channel recording/playback
Monitor Outputs	2
Aux Outputs	4
Power Supply	Internal
USB	USB playback and recording
Dimensions	177 x 482 x 89 mm
Weight	3.9kg (8.6 lbs)
