SoundCraft Ui16 User Manual

Ui12, Ui16 User Manual
7.3: CHORUS
FX EDIT > CHORUS
7.3: CHORUS
Chorus creates a lush, full sound by combining two or more signals together where one is unaffected and the
other signals vary in pitch very slightly over time. Chorus is commonly used to fatten up tracks and to add body
to guitars without colouring the original tone. Chorus can also be used with discretion to thicken a vocal track.
DENSITY
Adjust the density of the chorus effect
The more dense the chorus, the thicker and richer the result will be.
DETUNE
Amount of deviation from the pitch of the original signal
LPF
LowPassFilter-Frequenciesabovethisareltered/removed
Cut the high frequency content by adjusting the cut-o frequency of a shelving filter.

SoundCraft Ui16 Specifications

General

Channels	16
Mic Preamps	8
USB Playback	Yes
Built-in Wi-Fi	Yes
XLR Inputs	8
Aux Sends	4
Phantom Power	Yes
Sampling Rate	48 kHz
Bit Depth	24-bit
Ethernet Port	1
Remote Control	Remote control via HTML5-compatible browser
RCA Inputs	2
Control	Control via any device with a web browser
Wi-Fi	Built-in Wi-Fi
Microphone Preamps	8
USB Audio Interface	2-channel recording/playback
Monitor Outputs	2
Aux Outputs	4
Power Supply	Internal
USB	USB playback and recording
Dimensions	177 x 482 x 89 mm
Weight	3.9kg (8.6 lbs)
