SoundCraft Ui16 User Manual

Ui12, Ui16 User Manual
10.1.3: LAN
SETTINGS > NETWORK CONFIG > LAN
10.1.3: LAN SETTINGS
Use the Save/Update button to save LAN settings.
IMPORTANT: You must recycle the Ui power (turn the unit off and on) for settings to take effect.
Default Settings
LAN IP: 10.10.2.1
Subnet mask: 255.255.255.0
Direct Connection
Most computers with a GigaBit adapter will AutoNegotiate and so when connected directly to the unit (not via a
switch) there will be no need for an Ethernet crossover cable. Use a static IP for the computer, in the same range
as the unit, such as 10.10.2.5 and enter the IP address of the unit in the computer’s browser.
The Ui can connect to an existing wired LAN (Local Area Network) by connection the Ethernet port on
the side of the unit. This is the fastest, most secure method of connection to the Ui. Select the LAN
CongurationmenuinNetworkCongtoedittheLANsettings.
LAN
Enabled / Disabled
Enable or disable the Ui’s Ethernet port.
Address
DHCP / Manual
You can choose dynamic IP allocation, in which case the Ui will automatically allocate an IP, Netmask, and Gateway.
IfyouchooseManualIPallocation,youwillneedtocompletetheseeldsyourself.Pleaserefertoyournetwork
administrator for manual IP allocation.

SoundCraft Ui16 Specifications

General

Channels	16
Mic Preamps	8
USB Playback	Yes
Built-in Wi-Fi	Yes
XLR Inputs	8
Aux Sends	4
Phantom Power	Yes
Sampling Rate	48 kHz
Bit Depth	24-bit
Ethernet Port	1
Remote Control	Remote control via HTML5-compatible browser
RCA Inputs	2
Control	Control via any device with a web browser
Wi-Fi	Built-in Wi-Fi
Microphone Preamps	8
USB Audio Interface	2-channel recording/playback
Monitor Outputs	2
Aux Outputs	4
Power Supply	Internal
USB	USB playback and recording
Dimensions	177 x 482 x 89 mm
Weight	3.9kg (8.6 lbs)
