4.2.1: INPUT SUB-MENU
CHANNELS > INPUT SUB-MENU
4.2.1: INPUT SUB-MENU
Ui12, Ui16 User Manual
By long-clicking/tapping on a channel name you can access the channel sub-menu for access to various
channel parameters...
CHANNEL PRESETS
Recall and save whole channel settings - Factory and User preset banks.
RENAME
Renamethechannel.ThenewnamewillbeshownintheChannelNameelds.
COPY / PASTE SETTINGS
Copy the channel settings to the pasteboard. A ‘PASTE SETTINGS’ option will appear when you select another
input channel sub menu. Use that to paste the copied settings to that channel.
ASSIGN SUB GROUP
Choose a sub group for this channel. For example, you might want to assign all drum kit microphones to a ‘Drum
Kit’ sub group. Once assigned, the sub group assignment grid will be replaced with an ‘UNASSIGN
SUBGROUP’ option.
STEREO LINK
Create and stereo channel from two mono channels. Odd/even (L/R) pairs are linked, so if you link channel 2
(right), it will create a stereo channel with channel 1 (left).
RESET CHANNEL
Reset channel settings to their defaults.

SoundCraft Ui16 Specifications

General

Channels	16
Mic Preamps	8
USB Playback	Yes
Built-in Wi-Fi	Yes
XLR Inputs	8
Aux Sends	4
Phantom Power	Yes
Sampling Rate	48 kHz
Bit Depth	24-bit
Ethernet Port	1
Remote Control	Remote control via HTML5-compatible browser
RCA Inputs	2
Control	Control via any device with a web browser
Wi-Fi	Built-in Wi-Fi
Microphone Preamps	8
USB Audio Interface	2-channel recording/playback
Monitor Outputs	2
Aux Outputs	4
Power Supply	Internal
USB	USB playback and recording
Dimensions	177 x 482 x 89 mm
Weight	3.9kg (8.6 lbs)
