SoundCraft Ui16 User Manual

Ui12, Ui16 User Manual
5.5: AUX/FX SENDS
CHANNEL EDIT > AUX/FX SENDS (4 on Ui12, 6 on Ui16)
5.5: AUX/FX SENDS
The AUX and FX SENDS tabs in the EDIT screen are a convenient way to access all output
contributions for a single channel - as opposed to the ‘mix view’ approach of the dedicated AUX SEND
and FX SEND pages. The AUX SENDS view/tab for both phone and tablet software versions includes
PRE/POST and MUTE buttons for each send.
The FX SENDS view/tab for both phone and tablet software versions offer MUTE buttons and
selections for editing the settings of the different FX processors. In the phone software, clicking/
touching one of these takes you to an additional detail view to edit that FX processor.
For details on the internal FX processors, please see section 7.

SoundCraft Ui16 Specifications

General

Channels	16
Mic Preamps	8
USB Playback	Yes
Built-in Wi-Fi	Yes
XLR Inputs	8
Aux Sends	4
Phantom Power	Yes
Sampling Rate	48 kHz
Bit Depth	24-bit
Ethernet Port	1
Remote Control	Remote control via HTML5-compatible browser
RCA Inputs	2
Control	Control via any device with a web browser
Wi-Fi	Built-in Wi-Fi
Microphone Preamps	8
USB Audio Interface	2-channel recording/playback
Monitor Outputs	2
Aux Outputs	4
Power Supply	Internal
USB	USB playback and recording
Dimensions	177 x 482 x 89 mm
Weight	3.9kg (8.6 lbs)
