Ui12, Ui16 User Manual
5.1: DIGITECH
CHANNEL EDIT > DIGITECH
5.1: DIGITECH
DIGITECH ON/OFF
Turn DigiTech processing on or off
When DigiTech processing is turned o, the channel will revert to its standard input stage.
PRESETS
Open the PRESETS management pop-up
You can save and load settings presets for the DigiTech processing using this pop-up.
AMP CONTROLS
Adjust detailed settings for the selected amp model
The controls include GAIN, LEVEL, BASS, MID, and TREBLE. Use the GAIN control to overdrive the amp model.
CHANNEL CONTROLS
Single view editing of selected input channel controls
Available input channel sections are: FX, High Pass Filter, Notch Filter, Compressor, Gate

Other manuals for SoundCraft Ui16

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the SoundCraft Ui16 and is the answer not in the manual?

SoundCraft Ui16 Specifications

General IconGeneral
Channels16
Mic Preamps8
USB PlaybackYes
Built-in Wi-FiYes
XLR Inputs8
Aux Sends4
Phantom PowerYes
Sampling Rate48 kHz
Bit Depth24-bit
Ethernet Port1
Remote ControlRemote control via HTML5-compatible browser
RCA Inputs2
ControlControl via any device with a web browser
Wi-FiBuilt-in Wi-Fi
Microphone Preamps8
USB Audio Interface2-channel recording/playback
Monitor Outputs2
Aux Outputs4
Power SupplyInternal
USBUSB playback and recording
Dimensions177 x 482 x 89 mm
Weight3.9kg (8.6 lbs)
