Ui12, Ui16 User Manual
10.1.2: WI-FI
SETTINGS > NETWORK CONFIG > WI-FI
10.1.2: Wi-FI SETTINGS
Use the Save/Update button to save Wi-Fi settings.
IMPORTANT: You must recycle the Ui power (turn the unit off and on) for settings to take effect.
The Ui can connect to an existing Wi-Fi network / Hotspot, and you can access the control software via
theunit’sIPnumber(showninSettings>Network).SelecttheWi-FiCongurationmenuinNetwork
CongtoedittheWi-Fisettings.
Wi-Fi
Enabled / Disabled
Enable or disable the Wi-Fi connection.
SSID (Service Set Identier)
Text Entry
This is the name of the network you wish to connect to.
Password
Text Entry
This is the password for the network you wish to connect to.
Address
DHCP / Manual
You can choose dynamic IP allocation, in which case the Ui will automatically allocate an IP, Netmask, and Gateway.
IfyouchooseManualIPallocation,youwillneedtocompletetheseeldsyourself.Pleaserefertoyournetwork
administrator for manual IP allocation.

SoundCraft Ui16 Specifications

General

Channels	16
Mic Preamps	8
USB Playback	Yes
Built-in Wi-Fi	Yes
XLR Inputs	8
Aux Sends	4
Phantom Power	Yes
Sampling Rate	48 kHz
Bit Depth	24-bit
Ethernet Port	1
Remote Control	Remote control via HTML5-compatible browser
RCA Inputs	2
Control	Control via any device with a web browser
Wi-Fi	Built-in Wi-Fi
Microphone Preamps	8
USB Audio Interface	2-channel recording/playback
Monitor Outputs	2
Aux Outputs	4
Power Supply	Internal
USB	USB playback and recording
Dimensions	177 x 482 x 89 mm
Weight	3.9kg (8.6 lbs)
