4.5: SUB GROUP MASTER
CHANNELS > SUB GROUP MASTER CHANNEL (4 x Sub Groups)
4.5: SUB GROUP MASTER CHANNEL
Ui12, Ui16 User Manual
If you want to have control over the drum kit mix, for example, but also want single fader control over the
whole kit’s contribution to the mix, you would use a Sub Group.
When input channels are allocated to Sub Groups, either via the input channel sub-menu, or via the SUBS
screen in the DASHBOARD/METERS page, they are mixed together into a single stereo channel,
according to the relative positions of the main channel faders. That stereo channel is the Sub Group Master
and is used as a stereo input channel.
Sub Group Master channels have their own EDIT channels, as per any other Ui input channel.

SoundCraft Ui16 Specifications

General

Channels	16
Mic Preamps	8
USB Playback	Yes
Built-in Wi-Fi	Yes
XLR Inputs	8
Aux Sends	4
Phantom Power	Yes
Sampling Rate	48 kHz
Bit Depth	24-bit
Ethernet Port	1
Remote Control	Remote control via HTML5-compatible browser
RCA Inputs	2
Control	Control via any device with a web browser
Wi-Fi	Built-in Wi-Fi
Microphone Preamps	8
USB Audio Interface	2-channel recording/playback
Monitor Outputs	2
Aux Outputs	4
Power Supply	Internal
USB	USB playback and recording
Dimensions	177 x 482 x 89 mm
Weight	3.9kg (8.6 lbs)
