SoundCraft Ui16 User Manual

Ui12, Ui16 User Manual
5.2: PARAMETRIC EQ
CHANNEL EDIT > PARAMETRIC EQ
5.2: PARAMETRIC EQ
RESET
Reset the EQ to default values
The EQ is set ‘flat’, and frequency and Q values are reset to defaults.
BYPASS
Bypass the EQ section of channel processing
This control bypasses only the parametric EQ. HPF and De-Esser processing is unaected.
EQ / DE-ESSER FADER CONTROL
Choose EQ or De-Esser fader control
Controls for whichever is selected are assigned to the three control faders. For EQ, the faders show values for the
currently selected band.
DS - DE-ESSER BALL
Draggable graphic ‘ball’ for De-Esser control
Drag this graphic element to control. UP/DOWN adjusts Threshold, LEFT/RIGHT adjusts frequency; use a
pinch-gesture or mouse-wheel/track-pad scroll on DE-ESSER ball to adjust the ratio value. Double-click/tap to
reset.
1/2/3/4 - EQ BAND BALL
Draggable graphic ‘ball’ for EQ band control
Drag this graphic element to control. UP/DOWN adjusts Gain, LEFT/RIGHT adjusts frequency; use a pinch-
gesture or mouse-wheel/track-pad scroll on the EQ ball to adjust ‘Q’ value. Double-click/tap to reset an individual
band.

SoundCraft Ui16 Specifications

General

Channels	16
Mic Preamps	8
USB Playback	Yes
Built-in Wi-Fi	Yes
XLR Inputs	8
Aux Sends	4
Phantom Power	Yes
Sampling Rate	48 kHz
Bit Depth	24-bit
Ethernet Port	1
Remote Control	Remote control via HTML5-compatible browser
RCA Inputs	2
Control	Control via any device with a web browser
Wi-Fi	Built-in Wi-Fi
Microphone Preamps	8
USB Audio Interface	2-channel recording/playback
Monitor Outputs	2
Aux Outputs	4
Power Supply	Internal
USB	USB playback and recording
Dimensions	177 x 482 x 89 mm
Weight	3.9kg (8.6 lbs)
