SoundCraft Ui16 User Manual

Ui12, Ui16 User Manual
5.4: DYNAMICS
CHANNEL EDIT > DYNAMICS
5.4: DYNAMICS
ATTACK
Adjust the compressor Attack
This is the speed at which the compressor reacts and reaches the attenuation set by the RATIO parameter.
RELEASE
Adjust the compressor Release
This is the speed at which the compressor returns to ‘no attenuation’ after the signal level has fallen below the
threshold level.
GRM - METERING
Gain reduction metering
There are three meters: Input signal, output signal, and a meter showing the amount of attenuation currently
being applied due to the dynamics processing.
GAIN
Adjust the compressor Make-up Gain
Compression results in an overall reduction in signal level, so a GAIN control is provided to ‘make-up’ the lost gain.
Heavy compression plus make-up gain can often result in an increase in perceived overall loudness.
RESET
Reset the Dynamics for this channel to default values
BYPASS
Bypass the Dynamics for this channel

SoundCraft Ui16 Specifications

General

Channels	16
Mic Preamps	8
USB Playback	Yes
Built-in Wi-Fi	Yes
XLR Inputs	8
Aux Sends	4
Phantom Power	Yes
Sampling Rate	48 kHz
Bit Depth	24-bit
Ethernet Port	1
Remote Control	Remote control via HTML5-compatible browser
RCA Inputs	2
Control	Control via any device with a web browser
Wi-Fi	Built-in Wi-Fi
Microphone Preamps	8
USB Audio Interface	2-channel recording/playback
Monitor Outputs	2
Aux Outputs	4
Power Supply	Internal
USB	USB playback and recording
Dimensions	177 x 482 x 89 mm
Weight	3.9kg (8.6 lbs)
